Why Choose the Carlo Gavazzi IA18CSN08UCM1 Inductive Proximity Sensor?
The Carlo Gavazzi IA18CSN08UCM1 is a compact and reliable M18 NAMUR inductive proximity sensor designed for non-contact detection of metallic objects in industrial machinery and automation systems. As part of the Carlo Gavazzi IA series, this short-body sensor combines an extended sensing range with a NAMUR normally closed output and convenient M12 plug connection.
Using inductive sensing technology, the IA18CSN08UCM1 detects conductive metallic targets without physical contact, helping to minimise mechanical wear while providing repeatable switching in automated equipment. Its thermoplastic polyester housing and non-flush sensing arrangement provide an extended 8 mm nominal sensing distance for applications where additional target clearance is beneficial.
With a rated operating voltage of 7–9 V DC, a maximum output current of 9.35 mA and a maximum switching frequency of 200 Hz, the IA18CSN08UCM1 is designed for compatible NAMUR input circuits. Its M12 plug connection, IP67 protection and operating temperature range of -25 to +70 °C support dependable integration into industrial machinery.
Key Advantages
- Reliable non-contact detection of metallic targets for industrial automation.
- Extended 8 mm nominal sensing distance in an M18 cylindrical format.
- NAMUR normally closed (NC) output for compatible industrial interface equipment.
- Non-flush / unshielded mounting provides extended sensing capability.
- Durable thermoplastic polyester housing for industrial applications.
- M12 plug connection simplifies installation, replacement and maintenance.
- IP67 protection supports dependable operation in demanding environments.
Key Features
- Carlo Gavazzi IA series inductive proximity sensor.
- M18 × 1 cylindrical threaded housing.
- Compact short-body construction.
- 8 mm nominal sensing distance.
- NAMUR normally closed output.
- 7–9 V DC rated operating voltage.
- 9.35 mA maximum output current.
- 200 Hz maximum switching frequency.
- Non-flush / unshielded mounting configuration.
- M12 connector for detachable field wiring.
- Yellow LED status indication.
- IP67 enclosure protection.
Reliable NAMUR Metal Detection for Industrial Automation
Inductive proximity sensors detect metallic targets by generating an electromagnetic field at the sensing face and monitoring changes caused when conductive material enters that field. This contactless operating principle eliminates mechanical contact with the target, helping to reduce wear while providing repeatable position and presence detection in automated machinery.
The Carlo Gavazzi IA18CSN08UCM1 combines an 8 mm sensing range with NAMUR normally closed signalling and a compact M18 thermoplastic housing. Its non-flush sensing arrangement, detachable M12 connection and IP67 protection make it a practical solution for machinery and automation systems equipped with compatible NAMUR interfaces.
Typical Applications
- Industrial machine position sensing.
- Metal component presence detection.
- Conveyor and material handling systems.
- Automated production and assembly equipment.
- Packaging and processing machinery.
- Machine position and movement monitoring.
- Industrial systems using compatible NAMUR sensor interfaces.
