Why Choose the Carlo Gavazzi ICB30S30F15PO Inductive Proximity Sensor?
The Carlo Gavazzi ICB30S30F15PO is a compact and reliable M30 inductive proximity sensor designed for non-contact detection of metallic objects in industrial machinery and automation systems. As part of the Carlo Gavazzi ICB30 series, it combines an extended sensing range, robust nickel-plated brass housing and dependable solid-state switching for demanding industrial applications.
This sensor provides a 15 mm rated operating distance with flush mounting capability, allowing it to be integrated directly into metal mounting surfaces where space is limited. Its PNP normally open output provides straightforward interfacing with PLCs, control systems and industrial automation equipment, while integrated electrical protection helps maintain dependable operation.
With a 10–36 V DC supply, maximum output current of 200 mA and switching frequency up to 1 kHz, the ICB30S30F15PO is suitable for high-speed position, presence and object detection. The sensor features a short-body M30 threaded housing, a 2 m cable connection and IP67 environmental protection for installation in industrial environments.
Key Advantages
- Reliable inductive detection of metallic objects without physical contact.
- 15 mm rated sensing distance provides extended detection range.
- Flush-mountable M30 housing simplifies integration into machinery and metal mounting surfaces.
- PNP normally open output for compatibility with common industrial PLC and control inputs.
- Fast 1 kHz switching frequency supports high-speed automation applications.
- Robust nickel-plated brass construction with IP67 protection.
Key Features
- Carlo Gavazzi ICB30 inductive proximity sensor series.
- M30 cylindrical threaded housing.
- 15 mm rated operating distance.
- PNP normally open (NO) transistor output.
- 10–36 V DC operating voltage.
- Maximum output current of 200 mA.
- Maximum switching frequency of 1 kHz.
- 2 m integral cable connection.
- Yellow LED indication for output status and overload / short-circuit indication.
- Protection against reverse polarity, short circuit and voltage transients.
Reliable Non-Contact Detection for Industrial Automation
Inductive proximity sensors such as the Carlo Gavazzi ICB30S30F15PO detect metallic objects by generating an electromagnetic field at the sensing face. When a suitable metal target enters this field, the sensor switches its electronic output without requiring physical contact, helping reduce mechanical wear and improve reliability in repetitive industrial processes.
The ICB30 series is designed for industrial automation applications requiring extended sensing distances and robust construction. The flush-mountable design allows the ICB30S30F15PO to be installed within surrounding metal, while its fast solid-state PNP output makes it suitable for position sensing, machine sequencing, counting and presence detection.
Typical Applications
- Metal object presence and position detection.
- Industrial conveyors and material handling systems.
- Packaging and production machinery.
- Machine tool position sensing.
- Automated assembly and manufacturing equipment.
- Counting and high-speed detection applications.
- PLC-controlled industrial automation systems.
