Why Choose the Carlo Gavazzi IMC3 Magnetic Slot Sensor?
The Carlo Gavazzi IMC3 is a compact magnetic slot proximity sensor designed for reliable non-contact position detection in industrial automation and machine control applications. Part of the Carlo Gavazzi IM series, it uses a magnetic reed switching principle to provide dependable detection without the mechanical wear associated with conventional contact-operated switches.
The IMC3 features a normally closed (NC) contact and compact slot-style plastic housing measuring just 7 × 28 × 18.5 mm. Its small dimensions make it particularly suitable for machinery and automation equipment where installation space is restricted, while magnetic actuation enables reliable switching without physical contact between the sensor and target.
Designed for demanding industrial environments, the IMC3 provides a maximum contact switching voltage of 500 V AC, maximum switching current of 0.5 A and maximum switching power of 10 VA. It is supplied with a 0.5 m PVC cable and features an IP67 protection rating for dependable operation in industrial machinery.
Key Advantages
- Compact magnetic slot sensor for non-contact position detection.
- Normally closed (NC) reed contact for straightforward machine control integration.
- Small 7 × 28 × 18.5 mm housing for space-restricted installations.
- Maximum contact switching voltage of 500 V AC.
- Robust IP67 protection for demanding industrial environments.
- Non-contact magnetic operation helps minimise mechanical wear and maintenance.
Key Features
- Carlo Gavazzi IM series magnetic proximity sensor.
- Slot-style sensor housing for compact machine installations.
- Normally closed (NC) output function.
- Maximum switching voltage of 500 V AC.
- Maximum switching current of 0.5 A.
- Maximum switching power of 10 VA.
- Durable plastic housing.
- Factory-fitted 0.5 m PVC cable.
- IP67 protection rating.
- Operating temperature range of -25 to +75 °C.
Reliable Magnetic Detection for Industrial Machinery
Magnetic proximity sensors detect the presence of a suitable magnetic actuator without requiring direct physical contact. The magnetic field operates the sensor's internal reed contact, providing a simple and repeatable switching method for monitoring the position of machine components, guards and moving mechanisms.
The compact Carlo Gavazzi IM series is particularly suited to installations where available mounting space is limited. With its normally closed contact, robust IP67 construction and wide operating temperature range, the IMC3 provides dependable position feedback for industrial automation, handling equipment and machine control systems.
Typical Applications
- Industrial machine position detection.
- Automated production and assembly equipment.
- Machine guard and access position monitoring.
- Conveyor and material handling systems.
- Pneumatic and mechanical positioning equipment.
- OEM machinery and industrial automation systems.
