Why Choose the Carlo Gavazzi PH18CND10PAM1SA Diffuse-Reflective Photoelectric Sensor?
The Carlo Gavazzi PH18CND10PAM1SA is a compact diffuse-reflective photoelectric sensor designed for accurate, non-contact object detection in industrial automation and machine control applications. Part of the Carlo Gavazzi PH18 series, it combines an industrial M18 square-format housing with a rated sensing distance of up to 1000 mm.
The PH18CND10PAM1SA uses 625 nm modulated red light and detects objects directly from the light reflected by the target, eliminating the need for a separate reflector or receiver. Sensitivity is adjustable by potentiometer over approximately 50–1000 mm, providing flexibility when commissioning the sensor for different targets and operating conditions.
Operating from a 10–30 V DC supply, this model provides a PNP complementary NO+NC transistor output rated up to 100 mA. The integrated 4-pin M12 plug, fast 500 Hz operating frequency and IP67/IP69K protection make the PH18CND10PAM1SA a robust and convenient choice for packaging, material handling, production and washdown applications.
Key Advantages
- Compact diffuse-reflective sensor requiring no separate reflector or receiver.
- Adjustable sensing distance of approximately 50–1000 mm.
- PNP complementary NO+NC output provides both light and dark switching functions.
- Visible 625 nm red light assists with alignment and commissioning.
- Fast 500 Hz operating frequency supports responsive object detection.
- 4-pin M12 plug connection simplifies installation, servicing and replacement.
- IP67 and IP69K protection supports demanding industrial and washdown environments.
- Integrated short-circuit, reverse-polarity and transient protection enhances reliability.
Key Features
- Carlo Gavazzi PH18 photoelectric sensor series.
- M18 square-format diffuse-reflective sensor.
- Rated operating distance up to 1 m.
- Sensitivity adjustment by potentiometer.
- 625 nm InGaAlP red LED with modulated light.
- 10–30 V DC operating voltage.
- PNP transistor output.
- Complementary NO+NC switching with light/dark switching operation.
- Continuous output current up to 100 mA.
- 500 Hz operating frequency and ≤1 ms response time.
- Yellow output LED plus green signal-stability and power indication.
- 4-pin M12 connector for convenient machine wiring.
- IP67 / IP69K degree of protection.
- ECOLAB-compatible design with excellent EMC performance.
Reliable Diffuse-Reflective Detection for Industrial Automation
Diffuse-reflective photoelectric sensing places the emitter and receiver in the same housing. Light is projected towards the target and reflected back to the sensor, allowing objects to be detected from one side of the application without requiring a separate reflector. This makes the technology particularly convenient for conveyors, packaging machinery and automated production equipment.
The Carlo Gavazzi PH18CND10PAM1SA combines adjustable sensitivity with complementary PNP outputs and a fast 500 Hz operating frequency. Its compact ABS housing, M12 plug and IP69K protection provide a practical combination of accurate sensing, straightforward installation and environmental resistance for demanding machine applications.
Typical Applications
- Industrial object presence and position detection.
- Packaging and processing machinery.
- Conveyor and material handling systems.
- Component counting and positioning.
- Assembly and automated manufacturing equipment.
- Food and beverage production machinery.
- Washdown and demanding production environments.
- OEM machine building and factory automation.
