Why Choose the Carlo Gavazzi PH18CND10PAT1SA Photoelectric Sensor?
The Carlo Gavazzi PH18CND10PAT1SA is a compact diffuse-reflective photoelectric sensor designed for reliable non-contact object detection in industrial automation, packaging and material handling applications. Part of the Carlo Gavazzi PH18 series, it combines a compact square housing with M18-compatible mounting characteristics, making it particularly useful where installation space is restricted.
Using the diffuse-reflective sensing principle, the PH18CND10PAT1SA detects light reflected directly from the target, eliminating the need for a separate reflector or receiver. Its visible modulated red light assists with alignment and commissioning, while adjustable sensitivity allows the detection performance to be optimised for different target surfaces and operating distances.
Operating from a standard 10–30 V DC supply, the PH18CND10PAT1SA provides PNP complementary NO+NC transistor outputs for flexible connection to PLCs and industrial controllers. The T1 version incorporates a convenient pigtail connection, while robust environmental protection makes the sensor well suited to demanding machine and production environments.
Key Advantages
- Up to 1000 mm diffuse-reflective sensing distance for versatile object detection.
- Diffuse-reflective operation eliminates the need for a separate reflector or receiving sensor.
- PNP complementary NO+NC outputs provide flexible PLC and controller integration.
- Visible modulated red light simplifies sensor alignment and commissioning.
- Adjustable sensitivity allows optimisation for different targets and operating conditions.
- Compact square design with M18-compatible mounting suits space-conscious machinery.
- Pigtail connection combines compact sensor installation with convenient electrical connection.
Key Features
- Carlo Gavazzi PH18 photoelectric sensor series.
- Diffuse-reflective sensing principle.
- Up to 1000 mm rated operating distance.
- Modulated visible red light source.
- 10–30 V DC rated operating voltage.
- PNP transistor output.
- Complementary normally open + normally closed outputs.
- Selectable light/dark switching functionality.
- Adjustable sensing sensitivity.
- LED status indication for straightforward commissioning.
- Electrical protection for industrial DC control circuits.
- Pigtail electrical connection.
- Compact square plastic housing.
- Designed for demanding industrial environments.
Reliable Diffuse-Reflective Detection for Industrial Automation
Diffuse-reflective photoelectric sensors such as the Carlo Gavazzi PH18CND10PAT1SA transmit light towards the object being monitored and detect the light reflected directly from its surface. This enables products, components and materials to be detected without physical contact and without installing a separate reflector or receiving sensor on the opposite side of the detection point.
The PH18CND10PAT1SA is particularly suited to compact automation equipment where conventional cylindrical sensors may require excessive installation space. Its PNP complementary NO+NC outputs, adjustable sensing performance and pigtail connection provide flexible integration with PLC-controlled machinery, conveyors, packaging equipment and material handling systems.
Typical Applications
- Conveyor product and package detection.
- Packaging and labelling machinery.
- Material handling and logistics equipment.
- Presence and absence detection.
- Product counting applications.
- Component positioning and orientation systems.
- Automated assembly machinery.
- PLC-controlled manufacturing systems.
