ABB 1SDA100396R1 SACE Tmax XT5N 400 A four-pole fixed moulded case circuit breaker with front terminals and Ekip Dip LS/I electronic trip unit for industrial power distribution.
£1,660.45
The ABB 1SDA100396R1 is a premium 400 A moulded case circuit breaker (MCCB) engineered to deliver dependable protection for industrial and commercial low-voltage power distribution systems. As part of the proven ABB SACE Tmax XT5 series, this four-pole breaker combines high breaking capacity, electronic protection and robust construction for demanding electrical installations.
Equipped with the advanced Ekip Dip LS/I electronic trip unit, the breaker provides adjustable long-time overload protection together with selective and instantaneous short-circuit protection. These functions allow engineers to optimise protection settings for improved discrimination and system reliability.
With a rated uninterrupted current of 400 A, a maximum operating voltage of 690 V AC and a 36 kA breaking capacity, the ABB 1SDA100396R1 is ideal for switchboards, distribution panels, motor control centres and OEM electrical equipment requiring dependable circuit protection.
Moulded case circuit breakers such as the ABB XT5N 400 continuously monitor electrical circuits and disconnect the supply whenever overload or short-circuit conditions occur. This helps minimise equipment damage, reduce downtime and improve overall electrical system safety.
The integrated Ekip Dip LS/I trip unit allows precise protection coordination, making the breaker suitable for modern industrial installations where reliable operation and selective fault isolation are essential.
| Current | 400 A |
|---|---|
| Phase | Three Phase |
| Manufacturer | ABB |
| Series | SACE Tmax XT |
| Model | XT5N 400 Ekip Dip LS/I In=400 4p F F |
| Product ID | 1SDA100396R1 |
| Product type | Moulded case circuit breaker |
| Frame size | XT5 |
| Rated current | 400 A |
| Number of poles | 4 |
| Trip unit | Ekip Dip LS/I electronic release |
| Rated operating voltage | Up to 690 V AC |
| Rated insulation voltage | 1000 V |
| Rated impulse withstand voltage | 8 kV |
| Breaking capacity | 36 kA |
| Mounting version | Fixed |
| Terminal connection | Front terminals |
| Protection rating | IP20 |
| Standards | IEC 60947-2 |
| Dimensions (H × W × D) | 205 × 186 × 103.5 mm |
| Weight | Approx. 6.4 kg |
| EAN | 8056221004732 |
| HS Code | 85362090 |
| Country of Manufacture | Italy |
The ABB 1SDA100396R1 protects industrial and commercial electrical circuits against overloads and short circuits within low-voltage power distribution systems.
This MCCB has a rated uninterrupted current of 400 A.
The breaker features a four-pole fixed configuration, making it suitable for three-phase systems with neutral protection.
The breaker is equipped with an Ekip Dip LS/I electronic trip unit, providing adjustable overload and short-circuit protection.
It is commonly installed in industrial switchboards, commercial distribution panels, motor control centres and OEM electrical equipment.
ABB SACE Tmax XT moulded case circuit breakers are trusted by electrical engineers, panel builders and industrial maintenance teams for delivering reliable protection, excellent interruption performance and long-term operational reliability.
