ABB S301P-C25 single-pole miniature circuit breaker with a 25 A rating, Type C tripping characteristic and 25 kA breaking capacity for industrial and commercial circuit protection.
£35.19
The ABB 2CDS381001R0205, also known as the S301P-C25, is a high-performance single-pole miniature circuit breaker (MCB) from the ABB System pro M compact S300P series. It is engineered to provide dependable protection against overloads and short circuits in industrial and commercial electrical installations while offering a high fault interruption capability for demanding applications.
Designed for use in switchboards, distribution boards and industrial control panels, the S301P-C25 incorporates thermal overload and electromagnetic short-circuit protection. Its Type C tripping characteristic makes it particularly suitable for circuits supplying equipment with moderate inrush currents, including motors, transformers and power supplies.
With a 25 A rated current, a compact single-pole design and a 25 kA rated short-circuit breaking capacity, the ABB 2CDS381001R0205 delivers reliable circuit protection while ensuring straightforward DIN rail installation and long-term operational reliability.
The ABB S301P-C25 automatically disconnects electrical circuits when overloads or short circuits occur, helping to protect electrical wiring, machinery and connected equipment from damage. Its thermal trip responds to prolonged overloads, while the electromagnetic mechanism provides rapid disconnection during fault-current events.
The Type C characteristic allows the breaker to tolerate moderate temporary inrush currents without nuisance tripping, making it well suited to industrial control equipment, transformers, small motors and commercial electrical distribution systems.
| Current | 20 A |
|---|---|
| Phase | Single Phase |
| Manufacturer | ABB |
| Series | System pro M compact S300P |
| Model | S301P-C25 |
| Product ID | 2CDS381001R0205 |
| Product type | Miniature circuit breaker |
| Rated current | 25 A |
| Number of poles | 1 |
| Protected poles | 1 |
| Tripping characteristic | Type C |
| Rated voltage | 240 V AC |
| Voltage type | AC / DC |
| Frequency | 50 / 60 Hz |
| Rated insulation voltage (Ui) | 500 V |
| Rated impulse withstand voltage (Uimp) | 6 kV |
| Rated short-circuit breaking capacity | 25 kA |
| Energy limiting class | 3 |
| Protection rating | IP20 (IP40 when installed inside an enclosure) |
| Mounting type | DIN rail |
| Modular width | 1 module |
| Dimensions (H × W × D) | Approx. 88 × 17.5 × 69 mm |
| Weight | Approx. 0.12 kg |
| Operating temperature | -40 °C to +70 °C |
| Standards | IEC/EN 60898-1, IEC/EN 60947-2, UL 1077 |
| HS Code | 85362010 |
| Country of Manufacture | Germany |
It provides overload and short-circuit protection for industrial and commercial electrical circuits, particularly those with moderate inrush currents.
The ABB S301P-C25 has a rated current of 25 A.
A Type C miniature circuit breaker is designed for applications with moderate inrush currents, making it suitable for motors, transformers, lighting circuits and industrial equipment.
The ABB S301P-C25 provides a rated short-circuit breaking capacity of up to 25 kA.
It is designed for installation on a standard DIN rail inside electrical distribution boards, switchboards and industrial control panels.
ABB System pro M compact S300P miniature circuit breakers are trusted worldwide by electrical engineers, OEM manufacturers and panel builders for their high breaking capacity, dependable protection and long-term reliability.
