ABB S301P-C40 single-pole miniature circuit breaker with a 40 A rating, Type C tripping characteristic and 25 kA breaking capacity for industrial circuit protection.
£58.55
The ABB 2CDS381001R0217, also known as the S301P-C40, is a high-performance single-pole miniature circuit breaker (MCB) from the ABB System pro M compact S300P series. It is engineered to provide reliable protection against overloads and short circuits in industrial and commercial electrical installations where high fault interruption capability is essential.
The S301P-C40 combines thermal overload protection with electromagnetic short-circuit protection. Its Type C tripping characteristic is designed for circuits supplying equipment with moderate inrush currents, making it suitable for motors, transformers, power supplies and industrial control equipment.
With a 40 A rated current, a compact single-pole configuration and a 25 kA short-circuit breaking capacity, the ABB 2CDS381001R0217 delivers dependable circuit protection while offering straightforward DIN rail installation and long service life.
The ABB S301P-C40 automatically disconnects electrical circuits during overload and short-circuit conditions, protecting electrical wiring, machinery and connected equipment from damage. Its thermal trip responds to prolonged overloads, while its magnetic trip reacts almost instantly to fault currents.
The Type C characteristic is designed to tolerate moderate temporary inrush currents, making this breaker particularly suitable for industrial machinery, transformers, motor circuits and commercial electrical distribution systems.
| Current | 1 A |
|---|---|
| Phase | Single Phase |
| Manufacturer | ABB |
| Series | System pro M compact S300P |
| Model | S301P-C40 |
| Product ID | 2CDS381001R0217 |
| Product type | Miniature circuit breaker |
| Rated current | 40 A |
| Number of poles | 1 |
| Protected poles | 1 |
| Tripping characteristic | Type C |
| Rated voltage | 240 V AC |
| Voltage type | AC / DC |
| Frequency | 50 / 60 Hz |
| Rated insulation voltage (Ui) | 500 V |
| Rated impulse withstand voltage (Uimp) | 6 kV |
| Rated short-circuit breaking capacity | 25 kA |
| Energy limiting class | 3 |
| Protection rating | IP20 (IP40 when installed inside a suitable enclosure) |
| Mounting type | DIN rail |
| Modular width | 1 module |
| Dimensions (H × W × D) | Approx. 88 × 17.5 × 69 mm |
| Weight | Approx. 0.12 kg |
| Operating temperature | -40 °C to +70 °C |
| HS Code | 85362010 |
| Country of Manufacture | Germany |
It provides overload and short-circuit protection for industrial and commercial electrical circuits, particularly those supplying equipment with moderate inrush currents.
The ABB S301P-C40 has a rated current of 40 A.
A Type C miniature circuit breaker is designed to tolerate moderate temporary inrush currents, making it ideal for motors, transformers, lighting systems and industrial control equipment.
The ABB S301P-C40 provides a rated short-circuit breaking capacity of up to 25 kA.
It mounts directly onto a standard DIN rail inside electrical distribution boards, switchboards and industrial control panels.
ABB System pro M compact S300P miniature circuit breakers are trusted by electrical engineers, panel builders and OEM manufacturers for delivering dependable circuit protection, excellent fault interruption capability and long-term reliability.
