Why Choose the ABB S302P-Z6 Miniature Circuit Breaker?
The ABB S302P-Z6 (Part Number: 2CDS382001R0378) is a high-performance 3-pole miniature circuit breaker (MCB) designed to provide dependable protection against overloads and short circuits in industrial and commercial electrical installations. Part of the proven ABB System pro M compact S300P series, it offers exceptional reliability and high breaking capacity for critical applications requiring precise circuit protection.
Featuring a Z tripping characteristic, the S302P-Z6 is specifically engineered for highly sensitive circuits and electronic equipment where rapid disconnection is essential. Manufactured to recognised IEC, EN and UL standards, it combines robust protection with straightforward DIN rail installation for modern control panels and switchboards.
With a 6 A rated current, 3-pole configuration and a 25 kA breaking capacity, the ABB S302P-Z6 provides excellent protection for industrial automation systems, control circuits and sensitive electronic installations.
Key Advantages
- Industrial-grade 3-pole miniature circuit breaker.
- Z-curve tripping characteristic for highly sensitive electrical and electronic circuits.
- 6 A rated current for dependable circuit protection.
- 25 kA breaking capacity for demanding industrial environments.
- Compact DIN rail design enables fast installation.
- Manufactured to international IEC, EN and UL standards.
Key Features
- ABB System pro M compact S300P series.
- 3-pole (3P) configuration.
- 6 A rated current.
- Z tripping characteristic.
- Up to 415 V AC operating voltage.
- 25 kA rated breaking capacity.
- DIN rail mounting.
- High mechanical and electrical endurance.
Reliable Protection for Sensitive Electrical Circuits
The ABB S302P-Z6 automatically disconnects electrical circuits when overload or short-circuit conditions occur, helping to protect valuable equipment, wiring and connected devices from electrical damage.
Its Z-curve characteristic provides extremely fast magnetic tripping, making it particularly suitable for sensitive electronic equipment, control systems, PLCs, semiconductor devices and specialised industrial applications where rapid fault clearance is essential.
Typical Applications
- Industrial automation systems.
- PLC and control panels.
- Sensitive electronic equipment.
- Instrumentation circuits.
- Machine building and OEM installations.
- Commercial and industrial distribution boards.
