ABB DS201 C16 A100 1P+N RCBO with 16 A rated current, 100 mA Type A residual current protection, C tripping characteristic and 6 kA breaking capacity.
£166.82
The ABB 2CSR255180R2164, also known as the DS201 C16 A100, is a high quality residual current circuit breaker with overcurrent protection (RCBO) designed to protect single-phase electrical circuits against overloads, short circuits and earth leakage faults. Combining multiple protection functions into a single compact device, it helps simplify installation while improving electrical safety.
Part of the trusted ABB System pro M compact DS201 series, this RCBO features a 1P+N configuration occupying just two DIN modules. It provides protection against sinusoidal AC and pulsating DC earth fault currents using Type A residual current detection, making it suitable for residential, commercial and light industrial electrical installations.
With a rated current of 16 A, a C tripping characteristic and a rated residual operating current of 100 mA, the DS201 C16 A100 delivers dependable protection for final circuits operating from 230 V AC supplies.
The ABB DS201 C16 A100 continuously monitors both load current and earth leakage current, disconnecting the circuit automatically when overloads, short circuits or residual current faults occur. This integrated protection helps safeguard people, wiring and connected equipment while reducing the number of devices required within a distribution board.
Its compact two-module format and proven ABB reliability make it an ideal solution for new installations and electrical upgrades where space efficiency and dependable protection are important.
| Current | 16 A |
|---|---|
| Phase | Single Phase |
| Manufacturer | ABB |
| Series | DS201 |
| Model | DS201 C16 A100 |
| Product ID | 2CSR255180R2164 |
| EAN | 8012542738916 |
| Product type | Residual current circuit breaker with overcurrent protection (RCBO) |
| Configuration | 1P+N |
| Number of modules | 2 |
| Rated current | 16 A |
| Tripping characteristic | C |
| Residual current type | Type A |
| Rated residual operating current | 100 mA |
| Rated operating voltage | 230 / 240 V AC |
| Rated insulation voltage | 500 V |
| Rated impulse withstand voltage | 4 kV |
| Rated frequency | 50 / 60 Hz |
| Breaking capacity | 6 kA |
| Mounting type | DIN rail |
| Terminal protection | IP20 |
| Mechanical endurance | 20,000 operations |
| Electrical endurance | 10,000 operations |
| Standards | IEC/EN 61009-1, IEC/EN 61009-2-1 |
| HS Code | 85363010 |
| Country of Manufacture | Italy |
It protects single-phase electrical circuits against overloads, short circuits and earth leakage faults using one compact RCBO.
The ABB DS201 C16 A100 has a rated current of 16 A.
The device provides 100 mA Type A residual current protection.
It features a 1P+N configuration occupying two DIN modules.
The RCBO is designed for installation on a standard DIN rail inside electrical distribution boards.
ABB DS201 RCBOs are trusted by electricians, panel builders and electrical contractors for providing dependable combined overload and residual current protection in modern electrical installations.
