ABB S203M-D16 miniature circuit breaker from the S200M series featuring a 16 A rated current, D tripping characteristic, 3-pole configuration and 10 kA breaking capacity for commercial and industrial circuit protection.
£109.42
The ABB S203M-D16 is a robust miniature circuit breaker (MCB) designed to provide reliable overload and short-circuit protection in residential, commercial and industrial electrical installations. Part of the ABB System pro M compact S200M series, it delivers high breaking capacity, current limiting performance and compact DIN rail installation for professional distribution systems.
With a 16 A rated current and D tripping characteristic, the S203M-D16 is suitable for circuits with high inrush currents, including motors, transformers, solenoids and industrial equipment. Its 3-pole configuration provides coordinated protection across three-phase circuits.
The ABB S203M-D16 combines a durable modular housing, secure screw terminals and a high 10 kA breaking capacity. This makes it a dependable choice for control panels, distribution boards and machinery installations where safe, consistent and standards-compliant circuit protection is required.
Miniature circuit breakers such as the ABB S203M-D16 automatically disconnect electrical circuits when overload or short-circuit conditions occur. This helps protect cables, connected equipment and electrical installations from damage while supporting safer operation.
The D characteristic is designed for circuits with high starting currents, making the S203M-D16 suitable for motors, transformers, solenoids and other inductive equipment where short-duration inrush current is expected.
| Current | 16 A |
|---|---|
| Phase | Single Phase |
| Manufacturer | ABB |
| Series | S200M |
| Model | S203M-D16 |
| Manufacturer part number | 2CDS273001R0161 |
| EAN | 4016779601030 |
| Product type | Miniature circuit breaker |
| Rated current | 16 A |
| Tripping characteristic | D |
| Number of poles | 3P |
| Rated operational voltage | 400 / 440 V AC |
| Rated frequency | 50 / 60 Hz |
| Rated short-circuit breaking capacity | 10 kA |
| Rated ultimate short-circuit breaking capacity | 15 kA at 400 V AC |
| Rated insulation voltage | 440 V |
| Rated impulse withstand voltage | 4 kV |
| Current limiting class | 3 |
| Standards | IEC/EN 60898-1, IEC/EN 60947-2, UL 1077 |
| Terminal type | Screw terminals |
| Mounting type | DIN rail TH35 |
| Protection rating | IP20 |
| Dimensions (H × W × D) | approx. 88 × 52.5 × 69 mm |
| Weight | approx. 0.38 kg |
| HS Code | 85362010 |
| Country of Manufacture | Germany |
The ABB S203M-D16 is used to protect three-phase electrical circuits against overloads and short circuits, particularly in commercial and industrial applications with high inrush currents.
This miniature circuit breaker has a rated current of 16 A.
A D characteristic MCB is designed for circuits with high inrush currents, making it suitable for motors, transformers and inductive electrical loads.
The ABB S203M-D16 has a 3-pole configuration, providing protection for three-phase electrical circuits.
The breaker is designed for standard DIN rail mounting inside distribution boards, switchboards and electrical control panels.
ABB S200M miniature circuit breakers are widely specified by electrical contractors, panel builders and industrial engineers for dependable circuit protection in professional electrical installations.
