Original price was: £75.32.£47.00Current price is: £47.00.
The IMO B6BRC1N06-30 is a compact Residual Current Circuit Breaker with Overcurrent Protection (RCBO) designed to protect single-phase electrical circuits against earth leakage, overload and short-circuit faults. By combining residual-current and overcurrent protection within one device, it helps simplify distribution-board layouts, reduce wiring requirements and conserve valuable DIN rail space.
Featuring a 6 A rated current, 30 mA residual operating current, Type AC residual-current protection and a C curve tripping characteristic, the B6BRC1N06-30 is suited to control, lighting and auxiliary circuits containing equipment with moderate starting currents.
The device incorporates a 1 Pole + Neutral configuration, allowing both the live and neutral conductors to be disconnected when operated. Its 6 kA short-circuit breaking capacity, compact DIN rail construction and integrated test button make it a practical protective device for commercial, industrial and OEM electrical installations.
The IMO B6BRC1N06-30 monitors the protected circuit for residual-current imbalance, sustained overloads and short-circuit conditions. When a potentially hazardous fault is detected, the RCBO disconnects the circuit to help protect personnel, electrical wiring and connected equipment.
Its C curve operating characteristic makes it suitable for circuits containing equipment that may draw moderate inrush currents during start-up. Combining multiple protective functions within one device can also simplify installation, improve circuit-level fault identification and reduce the number of components required within the enclosure.
| Voltage | 230 V |
|---|---|
| HS Code | 8536201090 |
| Country of Manufacture | China |
It provides combined earth leakage, overload and short-circuit protection for 6 A single-phase electrical circuits.
The IMO B6BRC1N06-30 has a rated current of 6 A.
It provides 30 mA Type AC residual-current protection for alternating sinusoidal leakage currents.
A C curve RCBO accommodates higher starting currents than a B curve device, making it suitable for circuits containing moderate inductive loads, control equipment and small motors.
The device mounts onto a standard 35 mm DIN rail inside a compatible electrical distribution board or control panel.
IMO RCBOs provide electricians, panel builders and equipment manufacturers with compact protection against residual-current, overload and short-circuit faults across commercial, industrial and automation installations.{ "@context": "https://schema.org/", "@type": "Product", "name": "IMO B6BRC1N06-30 RCBO 6 A 30 mA Type AC C Curve", "sku": "B6BRC1N06-30", "mpn": "B6BRC1N06-30", "brand": { "@type": "Brand", "name": "IMO" }, "category": "Residual Current Circuit Breakers with Overcurrent Protection", "description": "IMO B6BRC1N06-30 RCBO featuring a 6 A rated current, 30 mA residual operating current, Type AC protection, C curve tripping characteristic and 1 Pole plus Neutral configuration.", "additionalProperty": [ { "@type": "PropertyValue", "name": "Rated current", "value": "6 A" }, { "@type": "PropertyValue", "name": "Residual operating current", "value": "30 mA" }, { "@type": "PropertyValue", "name": "Residual-current type", "value": "Type AC" }, { "@type": "PropertyValue", "name": "Tripping characteristic", "value": "C Curve" }, { "@type": "PropertyValue", "name": "Pole configuration", "value": "1 Pole + Neutral" }, { "@type": "PropertyValue", "name": "Breaking capacity", "value": "6 kA" } ] } { "@context": "https://schema.org", "@type": "FAQPage", "inLanguage": "en-GB", "mainEntity": [ { "@type": "Question", "name": "What is the IMO B6BRC1N06-30 used for?", "acceptedAnswer": { "@type": "Answer", "text": "It provides combined earth leakage, overload and short-circuit protection for 6 A single-phase electrical circuits." } }, { "@type": "Question", "name": "What is the rated current of this RCBO?", "acceptedAnswer": { "@type": "Answer", "text": "The IMO B6BRC1N06-30 has a rated current of 6 A." } }, { "@type": "Question", "name": "What residual-current protection does it provide?", "acceptedAnswer": { "@type": "Answer", "text": "It provides 30 mA Type AC residual-current protection for alternating sinusoidal leakage currents." } }, { "@type": "Question", "name": "What does the C curve characteristic mean?", "acceptedAnswer": { "@type": "Answer", "text": "A C curve RCBO accommodates higher starting currents than a B curve device, making it suitable for circuits containing moderate inductive loads, control equipment and small motors." } }, { "@type": "Question", "name": "How is the B6BRC1N06-30 installed?", "acceptedAnswer": { "@type": "Answer", "text": "The device mounts onto a standard 35 mm DIN rail inside a compatible electrical distribution board or control panel." } } ] }
