Why Choose the IMO B6CRC1N16-30 Compact RCBO?
The IMO B6CRC1N16-30 is a compact Residual Current Circuit Breaker with Overcurrent Protection (RCBO) designed to safeguard electrical circuits against earth leakage, overload and short-circuit faults. Combining the functions of an MCB and RCD into a single compact device, it simplifies installation whilst helping maximise available space within consumer units, distribution boards and electrical control panels.
Part of the IMO B6 Compact RCBO range, this model provides Type AC residual current protection, making it suitable for conventional AC electrical circuits. Its compact single-module construction, DIN rail mounting and finger-safe terminals make it ideal for residential, commercial and light industrial installations.
Featuring a 16 A rated current, 30 mA residual operating current, Type C tripping characteristic and a 6 kA short-circuit breaking capacity, the B6CRC1N16-30 delivers dependable protection for socket outlets, lighting circuits, heating systems and general-purpose electrical installations.
Key Advantages
- Combined earth leakage, overload and short-circuit protection.
- 16 A rated current suitable for a wide range of final circuits.
- 30 mA Type AC residual current protection for enhanced electrical safety.
- Type C tripping characteristic accommodates moderate inrush currents.
- 6 kA breaking capacity provides dependable fault interruption.
- Compact single-module design maximises available DIN rail space.
Key Features
- IMO B6 Compact RCBO series.
- 16 A rated current.
- 30 mA residual operating current.
- Type AC residual current protection.
- Type C tripping characteristic.
- 6 kA short-circuit breaking capacity.
- Single Pole + Neutral configuration.
- Compact single-module (18 mm) design.
- 240 V AC operation.
- 35 mm TS35 DIN rail mounting.
- Finger-safe screw terminals.
- Integrated test button.
Reliable Protection for Everyday Electrical Installations
The IMO B6CRC1N16-30 continuously monitors connected circuits for overloads, short circuits and earth leakage faults. If a fault is detected, the RCBO disconnects the electrical supply rapidly, helping protect personnel, equipment and property whilst reducing the risk of electric shock and electrical fires.
Its Type C tripping characteristic makes it particularly suitable for circuits supplying equipment with moderate starting currents, including lighting, transformers, contactors, heating equipment and general-purpose socket outlet circuits.
Typical Applications
- Socket outlet circuits.
- Lighting installations.
- Heating systems.
- Residential consumer units.
- Commercial distribution boards.
- Control panels.
- OEM machinery.
- General-purpose electrical circuits.
