Original price was: £75.32.£47.00Current price is: £47.00.
The IMO B6CRC1N25-30 is a compact and dependable Residual Current Circuit Breaker with Overcurrent Protection (RCBO) designed to protect single-phase electrical circuits against earth leakage, overload and short-circuit faults. Combining the functions of an MCB and an RCD within one device, it provides comprehensive circuit protection while reducing the amount of DIN rail space required inside a consumer unit or distribution board.
Part of the IMO B6 circuit protection range, this RCBO is suitable for residential, commercial and light industrial electrical installations. Its C curve operating characteristic allows it to accommodate moderate starting currents from equipment such as small motors, fluorescent lighting, transformers and inductive loads while still providing reliable protection during fault conditions.
With a rated current of 25 A, a 30 mA residual operating current and a 230 V AC single-phase supply, the B6CRC1N25-30 is ideal for protecting dedicated socket circuits, fixed appliances, heating equipment and other final circuits. Its compact 1P+N construction enables straightforward installation on a standard 35 mm DIN rail.
The IMO B6CRC1N25-30 monitors current flowing through the protected circuit and rapidly disconnects the supply when an overload, short circuit or residual current fault is detected. This combined protection helps reduce the risk of electric shock, damaged wiring, electrical fires and equipment failure.
By incorporating residual current and overcurrent protection into one compact unit, the RCBO allows individual circuits to be isolated without unnecessarily disconnecting unrelated circuits. This can improve fault identification, system availability and maintenance efficiency within modern electrical installations.
| Voltage | 230 V |
|---|---|
| HS Code | 8536201090 |
| Country of Manufacture | China |
It is used to protect single-phase electrical circuits against overloads, short circuits and AC residual current faults.
The B6CRC1N25-30 has a rated current of 25 A.
The 30 mA rating is the residual operating current at which the RCBO disconnects the circuit to provide additional protection against electric shock.
A C curve RCBO is designed to tolerate moderate starting currents and is commonly used for circuits supplying lighting, transformers, small motors and similar inductive loads.
The RCBO mounts onto a standard 35 mm DIN rail inside a compatible consumer unit, distribution board or electrical enclosure.
IMO B6 circuit protection devices are used by electricians, panel builders and electrical contractors requiring compact construction, straightforward installation and reliable protection for residential, commercial and industrial systems.{ "@context": "https://schema.org/", "@type": "Product", "name": "IMO B6CRC1N25-30 RCBO 25A 30mA C Curve 6kA", "sku": "B6CRC1N25-30", "mpn": "B6CRC1N25-30", "brand": { "@type": "Brand", "name": "IMO Precision Controls" }, "category": "Residual Current Circuit Breakers", "description": "IMO B6CRC1N25-30 RCBO with a 25 A rated current, C curve overcurrent characteristic, 30 mA residual current protection and 6 kA breaking capacity.", "additionalProperty": [ { "@type": "PropertyValue", "name": "Rated current", "value": "25 A" }, { "@type": "PropertyValue", "name": "Tripping characteristic", "value": "C Curve" }, { "@type": "PropertyValue", "name": "Residual operating current", "value": "30 mA" }, { "@type": "PropertyValue", "name": "Rated voltage", "value": "230 V AC" }, { "@type": "PropertyValue", "name": "Breaking capacity", "value": "6 kA" } ] } { "@context": "https://schema.org", "@type": "FAQPage", "inLanguage": "en-GB", "mainEntity": [ { "@type": "Question", "name": "What is the IMO B6CRC1N25-30 used for?", "acceptedAnswer": { "@type": "Answer", "text": "It is used to protect single-phase electrical circuits against overloads, short circuits and AC residual current faults." } }, { "@type": "Question", "name": "What is the rated current of this RCBO?", "acceptedAnswer": { "@type": "Answer", "text": "The B6CRC1N25-30 has a rated current of 25 A." } }, { "@type": "Question", "name": "What does the 30 mA rating mean?", "acceptedAnswer": { "@type": "Answer", "text": "The 30 mA rating is the residual operating current at which the RCBO disconnects the circuit to provide additional protection against electric shock." } }, { "@type": "Question", "name": "What does the C curve characteristic indicate?", "acceptedAnswer": { "@type": "Answer", "text": "A C curve RCBO is designed to tolerate moderate starting currents and is commonly used for circuits supplying lighting, transformers, small motors and similar inductive loads." } }, { "@type": "Question", "name": "How is the B6CRC1N25-30 installed?", "acceptedAnswer": { "@type": "Answer", "text": "The RCBO mounts onto a standard 35 mm DIN rail inside a compatible consumer unit, distribution board or electrical enclosure." } } ] }
