Original price was: £89.88.£56.10Current price is: £56.10.
The IMO B6CRC1N32-30-A is a compact Residual Current Circuit Breaker with Overcurrent Protection (RCBO) that combines protection against earth leakage, overloads and short circuits in a single device. Designed to comply with IEC/EN 61009-1, this Type A RCBO detects both alternating residual currents and pulsating DC residual currents, making it ideal for modern electrical installations containing electronic equipment, switched-mode power supplies and other sensitive loads.
Combining the functions of an MCB and an RCD, the B6CRC1N32-30-A provides comprehensive circuit protection while reducing the amount of space required inside consumer units and distribution boards. Its compact single-module design, finger-safe terminals and DIN rail mounting allow quick installation and dependable long-term performance.
With a 32 A rated current, C curve tripping characteristic, 30 mA residual operating current and 230 V AC operation, this RCBO is ideal for socket circuits, lighting installations, commercial distribution boards and industrial control panels requiring enhanced residual current protection.
The IMO B6CRC1N32-30-A continuously monitors both overload current and residual leakage current, disconnecting the circuit rapidly whenever dangerous fault conditions occur. Type A protection makes it suitable for installations supplying electronic equipment that may generate pulsating DC leakage currents.
Its compact design allows individual circuit protection while simplifying fault finding and reducing unnecessary power interruptions. The device is suitable for use in residential, commercial and light industrial installations requiring dependable combined protection.
| Voltage | 230 V |
|---|---|
| HS Code | 8536201090 |
| Country of Manufacture | China |
It provides combined overload, short-circuit and Type A residual current protection for single-phase electrical circuits.
Type A RCBOs detect both alternating residual currents and pulsating DC residual currents produced by modern electronic equipment.
A 30 mA residual operating current provides additional protection against electric shock and helps improve electrical safety.
The device clips directly onto a standard 35 mm DIN rail and occupies a compact single-module width within a compatible distribution board.
The RCBO is manufactured in accordance with IEC/EN 61009-1 for residual current circuit breakers with integral overcurrent protection.
IMO B6 Type A RCBOs are trusted by electricians, panel builders and OEM manufacturers for reliable circuit protection, compact installation and dependable performance across residential, commercial and industrial applications.{ "@context": "https://schema.org/", "@type": "Product", "name": "IMO B6CRC1N32-30-A Type A RCBO 32A 30mA C Curve", "sku": "B6CRC1N32-30-A", "mpn": "B6CRC1N32-30-A", "brand": { "@type": "Brand", "name": "IMO Precision Controls" }, "category": "Residual Current Circuit Breakers", "description": "IMO B6CRC1N32-30-A Type A RCBO featuring 32 A rated current, C curve tripping characteristic, 30 mA residual current protection and 6 kA breaking capacity for modern electrical installations.", "additionalProperty": [ { "@type": "PropertyValue", "name": "Rated current", "value": "32 A" }, { "@type": "PropertyValue", "name": "Residual current type", "value": "Type A" }, { "@type": "PropertyValue", "name": "Residual operating current", "value": "30 mA" }, { "@type": "PropertyValue", "name": "Rated voltage", "value": "230 V AC" }, { "@type": "PropertyValue", "name": "Breaking capacity", "value": "6 kA" } ] } { "@context": "https://schema.org", "@type": "FAQPage", "inLanguage": "en-GB", "mainEntity": [ { "@type": "Question", "name": "What is the IMO B6CRC1N32-30-A used for?", "acceptedAnswer": { "@type": "Answer", "text": "It provides combined overload, short-circuit and Type A residual current protection for single-phase electrical circuits." } }, { "@type": "Question", "name": "What is the advantage of a Type A RCBO?", "acceptedAnswer": { "@type": "Answer", "text": "Type A RCBOs detect both alternating residual currents and pulsating DC residual currents produced by modern electronic equipment." } }, { "@type": "Question", "name": "What does the 30 mA trip sensitivity provide?", "acceptedAnswer": { "@type": "Answer", "text": "A 30 mA residual operating current provides additional protection against electric shock and helps improve electrical safety." } }, { "@type": "Question", "name": "How is this RCBO installed?", "acceptedAnswer": { "@type": "Answer", "text": "The device clips directly onto a standard 35 mm DIN rail and occupies a compact single-module width within a compatible distribution board." } }, { "@type": "Question", "name": "Which standards does the B6CRC1N32-30-A comply with?", "acceptedAnswer": { "@type": "Answer", "text": "The RCBO is manufactured in accordance with IEC/EN 61009-1 for residual current circuit breakers with integral overcurrent protection." } } ] }
