Original price was: £75.32.£47.00Current price is: £47.00.
The IMO B6CRC1N32-30 is a compact and reliable Residual Current Circuit Breaker with Overcurrent Protection (RCBO) designed to protect electrical installations against earth leakage, overload and short-circuit faults. Combining the functions of an MCB and an RCD within a single device, it provides comprehensive circuit protection while conserving valuable space inside consumer units, distribution boards and electrical control panels.
Part of the IMO B6 circuit protection range, this RCBO features a C curve tripping characteristic suitable for circuits containing equipment with moderate starting currents. Its single-module construction, finger-protected terminals and contact position indicator support straightforward installation, inspection and maintenance in residential, commercial and light industrial environments.
With a rated current of 32 A, a 30 mA residual operating current and a 240 V AC rated operational voltage, the B6CRC1N32-30 is suitable for protecting higher-load final circuits such as socket outlets, fixed appliances, heating equipment and other single-phase electrical loads. The device mounts onto a standard DIN rail and includes the neutral pole on the left-hand side.
The IMO B6CRC1N32-30 monitors the protected circuit for overcurrent and residual current faults. When an overload, short circuit or earth leakage condition occurs, the RCBO disconnects the affected circuit to help reduce the risk of electric shock, wiring damage, electrical fires and equipment failure.
By providing overcurrent and residual current protection within one compact device, the RCBO enables individual circuit protection and isolation without unnecessarily disconnecting unrelated circuits. Its C curve response is suitable for many general-purpose circuits that may experience moderate inrush currents during normal operation.
| Voltage | 230 V |
|---|---|
| HS Code | 8536201090 |
| Country of Manufacture | China |
It provides combined overload, short-circuit and AC residual current protection for single-phase electrical circuits.
The B6CRC1N32-30 has a rated current of 32 A.
The 30 mA rating is the residual operating current at which the RCBO is designed to disconnect the circuit, providing additional protection against electric shock.
A C curve RCBO is designed to accommodate moderate inrush currents and is commonly used for circuits supplying equipment such as transformers, lighting systems and small motors.
The device mounts onto a standard DIN rail conforming to EN 60715 and occupies a single 18 mm module within a compatible electrical enclosure.
IMO B6 RCBOs are used by electricians, electrical contractors and panel builders requiring compact construction, straightforward installation and dependable protection for residential, commercial and light industrial circuits.{ "@context": "https://schema.org/", "@type": "Product", "name": "IMO B6CRC1N32-30 RCBO 32A 30mA C Curve 6kA", "sku": "B6CRC1N32-30", "mpn": "B6CRC1N32-30", "brand": { "@type": "Brand", "name": "IMO Precision Controls" }, "category": "Residual Current Circuit Breakers", "description": "IMO B6CRC1N32-30 RCBO with a 32 A rated current, C curve overcurrent characteristic, 30 mA Type AC residual current protection and 6 kA short-circuit capacity.", "additionalProperty": [ { "@type": "PropertyValue", "name": "Rated current", "value": "32 A" }, { "@type": "PropertyValue", "name": "Tripping characteristic", "value": "C Curve" }, { "@type": "PropertyValue", "name": "Residual operating current", "value": "30 mA" }, { "@type": "PropertyValue", "name": "Rated operational voltage", "value": "240 V AC" }, { "@type": "PropertyValue", "name": "Rated short-circuit capacity", "value": "6 kA" } ] } { "@context": "https://schema.org", "@type": "FAQPage", "inLanguage": "en-GB", "mainEntity": [ { "@type": "Question", "name": "What is the IMO B6CRC1N32-30 used for?", "acceptedAnswer": { "@type": "Answer", "text": "It provides combined overload, short-circuit and AC residual current protection for single-phase electrical circuits." } }, { "@type": "Question", "name": "What is the rated current of this RCBO?", "acceptedAnswer": { "@type": "Answer", "text": "The B6CRC1N32-30 has a rated current of 32 A." } }, { "@type": "Question", "name": "What does the 30 mA residual current rating mean?", "acceptedAnswer": { "@type": "Answer", "text": "The 30 mA rating is the residual operating current at which the RCBO is designed to disconnect the circuit, providing additional protection against electric shock." } }, { "@type": "Question", "name": "What does the C curve characteristic indicate?", "acceptedAnswer": { "@type": "Answer", "text": "A C curve RCBO is designed to accommodate moderate inrush currents and is commonly used for circuits supplying equipment such as transformers, lighting systems and small motors." } }, { "@type": "Question", "name": "How is the B6CRC1N32-30 installed?", "acceptedAnswer": { "@type": "Answer", "text": "The device mounts onto a standard DIN rail conforming to EN 60715 and occupies a single 18 mm module within a compatible electrical enclosure." } } ] }
