Why Choose the IMO US10C3002A UL1077 Miniature Circuit Breaker?
The IMO US10C3002A is a compact UL1077 supplementary miniature circuit breaker (MCB) engineered to provide dependable overcurrent protection for industrial control panels, OEM machinery and automation systems. Manufactured by IMO Precision Controls, this three-pole protective device safeguards electrical circuits against overloads and short circuits while delivering reliable long-term performance in demanding industrial environments.
Designed for industrial applications, the US10C3002A features a C curve tripping characteristic, making it ideal for circuits with moderate inrush currents generated by motors, transformers, contactors and switched-mode power supplies. Its compact DIN rail mounting format enables fast installation and seamless integration into modern electrical control cabinets.
With a 2 A rated current, 3-pole configuration and a 10 kA short-circuit breaking capacity, the IMO US10C3002A provides reliable supplementary protection for industrial control equipment, machine building and automation systems.
Key Advantages
- Compact UL1077 supplementary miniature circuit breaker.
- 2 A rated current for sensitive industrial control circuits.
- 3-pole configuration for simultaneous three-phase protection and isolation.
- C curve tripping characteristic suitable for moderate inrush current applications.
- 10 kA short-circuit breaking capacity.
- Simple DIN rail installation for electrical control panels.
Key Features
- IMO Precision Controls US10 Series.
- UL1077 supplementary protector.
- 2 A rated current.
- 3-pole design.
- C curve tripping characteristic.
- 10 kA interrupting capacity.
- Thermal-magnetic overcurrent protection.
- DIN rail mounting for industrial control panels.
- Suitable for AC and DC industrial control applications.
Reliable Protection for Industrial Control Circuits
The IMO US10C3002A protects industrial electrical circuits by disconnecting power during overload and short-circuit conditions. Its thermal-magnetic mechanism combines thermal overload protection with rapid magnetic fault response, helping safeguard machinery, automation equipment and valuable electrical components.
As a UL1077 supplementary protector, the US10C3002A is intended for installation within electrical equipment where suitable branch-circuit protection is already provided. Its compact modular construction makes it particularly suitable for industrial control panels, OEM machinery and process automation systems.
Typical Applications
- Industrial control panels.
- Automation systems.
- OEM machinery.
- Instrumentation and control circuits.
- Motor control circuits.
- Power supply and transformer protection.
- Process automation equipment.
