US10C3005A IMO 10kA UL1077 MCB 3 pole 5A C Curve

Q: What is the current rating of this circuit breaker?

This model has a 5 A rated current.

Q: What trip characteristic does it use?

The breaker features a C Curve tripping characteristic, making it suitable for circuits with moderate inrush currents.

Q: What interrupt rating does the breaker provide?

The IMO US10C3005A offers a 10 kA breaking capacity for reliable fault interruption.

SKU: US10C3005AMPN: US10C3005A

List Price £36.00 ex VAT

Your Price (ex VAT) Save 25%

£27.11 25% OFF

You save £8.89 per unit

Manufacturer Lead Time Please contact us for a delivery time before you order

Get the best trade prices Trade exclusive

Create a trade account to unlock exclusive pricing, special offers and more.

Quantity:

SUBTOTAL (EX VAT) £27.11

Trade pricing is personalised to your account

Manufacturer Lead Time

£27.11

Why Choose the IMO US10C3005A Miniature Circuit Breaker?

The IMO US10C3005A is a high-performance UL1077 supplementary miniature circuit breaker (MCB) designed to provide dependable overcurrent protection for industrial control panels, OEM machinery and electrical equipment. Manufactured by IMO Precision Controls, this compact three-pole circuit breaker combines reliable circuit protection with robust performance for demanding industrial applications.

Designed for panel builders and machine manufacturers, the US10C3005A offers fast and reliable protection against overloads and short circuits. Its compact DIN rail mounted design allows straightforward installation into control cabinets while ensuring compliance with industrial electrical protection requirements.

Featuring a 5 A current rating, C Curve tripping characteristic and an impressive 10 kA interrupting capacity, the IMO US10C3005A is well suited for protecting control circuits, motors, automation equipment and industrial machinery operating on three-phase electrical systems.

Key Advantages

Compact three-pole UL1077 supplementary protector.
5 A rated current for industrial control circuits.
C Curve tripping characteristic suitable for moderate inrush currents.
10 kA breaking capacity provides reliable fault protection.
DIN rail mounting for fast installation in control panels.
Ideal for OEM machinery, automation systems and electrical distribution panels.

Key Features

IMO Precision Controls supplementary circuit breaker.
Model: US10C3005A.
Three-pole configuration.
5 A rated current.
C Curve trip characteristic.
10 kA interrupt rating.
UL1077 recognised supplementary protector.
DIN rail mounting for industrial control panels.

Reliable Circuit Protection for Industrial Equipment

Supplementary circuit breakers such as the IMO US10C3005A provide dependable protection for industrial control equipment by disconnecting electrical circuits when overload or fault conditions occur. This helps minimise equipment damage, reduce downtime and improve overall system reliability.

Its compact DIN rail design makes integration into electrical control cabinets straightforward, while the three-pole construction provides protection for three-phase circuits commonly found in industrial automation and machine building applications.

Typical Applications

Industrial control panels.
OEM machinery.
Factory automation systems.
Motor control circuits.
Electrical distribution cabinets.
Machine building and process control equipment.

Technical Specifications

Current	5 A
Phase	Three Phase
Manufacturer	IMO Precision Controls
Series	US10C
Model	US10C3005A
Product type	Supplementary miniature circuit breaker (MCB)
Standard	UL1077
Rated current	5 A
Number of poles	3
Trip characteristic	C Curve
Breaking capacity	10 kA
Mounting type	DIN rail
Application	Industrial control panel protection
Protection	Overload and short-circuit protection
HS Code	8536201090
Country of Manufacture	India
Poles	3-pole
Device Type	MCB
Trip Curve	C curve
Breaking Capacity	10 kA

Frequently Asked Questions

What is the IMO US10C3005A used for?

The US10C3005A is a three-pole UL1077 supplementary circuit breaker designed to provide overload and short-circuit protection for industrial control circuits and machinery.

What is the current rating of this circuit breaker?

This model has a 5 A rated current.

What trip characteristic does it use?

The breaker features a C Curve tripping characteristic, making it suitable for circuits with moderate inrush currents.

What interrupt rating does the breaker provide?

The IMO US10C3005A offers a 10 kA breaking capacity for reliable fault interruption.

Where is the US10C3005A typically installed?

It is commonly installed on DIN rails inside industrial electrical control panels, automation systems and OEM machinery.

Trusted for Industrial Circuit Protection

IMO Precision Controls supplementary circuit breakers are widely used by panel builders, automation engineers and OEM manufacturers to provide dependable protection for industrial electrical systems and control equipment.
