Why Choose the ABB E9F10GG10 E 9F10 GG10 Fuse?
The ABB E9F10GG10, type code E 9F10 GG10, is a 10.3 × 38 mm cylindrical gG fuse link designed for general protection of cables, lines and electrical circuits. Part of the ABB E 9F cylindrical fuse range, it provides full-range protection against both overload and short-circuit currents in installation and industrial applications.
Rated at 10 A, the E 9F10 GG10 combines a 500 V AC rated voltage with a high 120 kA maximum breaking capacity. Its gG utilisation category makes it suitable for general-purpose circuit protection, including electrical cables, transformers, electronic devices and other compatible low-voltage equipment.
The E9F10GG10 has a power loss of 1.3 W at rated operating conditions and uses robust ceramic construction. Its standard 10.3 × 38 mm cylindrical dimensions and approximately 0.007 kg unit weight make it a compact protection solution for industrial automation switchboards, distribution panels and control equipment.
Key Advantages
- General-purpose gG fuse for overload and short-circuit protection.
- 10 A rated current for compatible low-voltage circuits.
- 500 V AC rated voltage for industrial and installation applications.
- High 120 kA maximum breaking capacity for dependable fault interruption.
- Compact 10.3 × 38 mm cylindrical format for compatible fuseholders.
- Full-range protection suitable for cables, lines and electrical equipment.
Key Features
- ABB E 9F gG cylindrical fuse range.
- 10 A rated current.
- 500 V AC rated voltage.
- 120 kA maximum breaking capacity.
- gG utilisation category for general-purpose full-range protection.
- 10.3 × 38 mm fuse size.
- 1.3 W power loss at rated operating conditions per pole.
- Fast tripping characteristic suited to cables, transformers and electronic equipment.
- Robust ceramic construction.
Fast Full-Range Protection for Electrical Circuits
ABB E 9F gG fuse links are designed to protect against both overload and short-circuit currents. Their fast tripping characteristics make them particularly suitable for protecting electrical cables, transformers and electronic equipment in industrial automation switchboards and general low-voltage installations.
The ABB E 9F10 GG10 combines a 10 A current rating with a high 120 kA fault interruption capability in the compact 10.3 × 38 mm cylindrical format. This combination provides dependable, replaceable overcurrent protection for control systems, distribution equipment and other compatible electrical installations.
Typical Applications
- Industrial automation switchboards.
- Cable and conductor protection.
- Electrical distribution panels.
- Transformer protection.
- Electronic and electrical equipment protection.
- Machinery and industrial control systems.
- Commercial low-voltage installations.
- Compatible 10.3 × 38 mm cylindrical fuseholders and fuse disconnectors.
