Why Choose the ABB E9F10GG16 Cylindrical Fuse?
The ABB E9F10GG16, also designated E 9F10 GG16, is a high-performance gG cylindrical fuse link designed to provide full-range protection against overload and short-circuit currents in low-voltage electrical installations. As part of the ABB E 9F fuse range, it is designed for reliable protection of cables, lines and electrical equipment in installation and industrial applications.
This fuse combines a gG full-range operating characteristic with a standard 10.3 × 38 mm cylindrical format. Its fast protection characteristics make it suitable for use with compatible cylindrical fuse holders and fuse disconnectors in industrial automation switchboards, control panels and electrical distribution systems.
With a rated current of 16 A, a rated voltage of 500 V AC and a maximum breaking capacity of 120 kA, the E9F10GG16 provides dependable protection where effective interruption of potentially high fault currents is required.
Key Advantages
- Reliable gG full-range protection against overloads and short circuits.
- 16 A rated current for electrical distribution and control circuits.
- 500 V AC rated voltage for low-voltage installations.
- 120 kA maximum breaking capacity for high fault-current interruption.
- Standard 10.3 × 38 mm cylindrical format for compatible fusegear.
- Suitable for general protection of cables and lines in industrial and installation applications.
Key Features
- ABB E 9F gG cylindrical fuse series.
- 16 A rated current.
- 500 V AC rated voltage.
- gG fuse classification for general-purpose full-range protection.
- 10.3 × 38 mm cylindrical dimensions.
- 120 kA maximum breaking capacity.
- 1.9 W power loss at rated operating conditions per pole.
- Ceramic construction with silver-plated copper contacts.
- Designed in accordance with IEC 60269-2.
Reliable Protection for Low-Voltage Circuits
gG cylindrical fuse links provide full-range protection by responding to both sustained overload currents and severe short-circuit faults. This helps protect cables, conductors and connected electrical equipment against damage while providing dependable interruption of fault currents.
The ABB E 9F gG range is particularly suited to industrial automation switchboards and low-voltage distribution applications. The E9F10GG16 combines a compact cylindrical design with high breaking capacity and can be used with compatible E90 fuse holders to provide effective protection for industrial and commercial circuits.
Typical Applications
- Industrial automation switchboards.
- Electrical distribution and control panels.
- Cable and conductor protection.
- Transformer and electrical equipment protection.
- Industrial machinery and control circuits.
- Commercial and industrial low-voltage installations.
