Why Choose the ABB 1SDA100605R1 Ekip Touch Measuring LSIG Trip Unit?
The ABB 1SDA100605R1 is an advanced Ekip Touch Measuring LSIG electronic trip unit designed for ABB SACE Tmax XT5 moulded case circuit breakers. It provides intelligent circuit protection, accurate electrical measurement and advanced monitoring functions for modern low-voltage power distribution systems.
Featuring comprehensive LSIG protection, the ABB Ekip Touch unit protects against overload, short circuit, instantaneous faults and earth faults while allowing engineers to configure protection settings and monitor electrical performance through its integrated touch display interface.
With a 630 A rated current, three-pole configuration and compatibility with ABB XT5 circuit breakers, the 1SDA100605R1 is ideal for industrial switchgear, automation systems and commercial electrical installations requiring reliable and intelligent protection.
Key Advantages
- Advanced ABB Ekip Touch electronic protection technology.
- LSIG protection functions for complete circuit safety.
- 630 A rated current for demanding low-voltage applications.
- Integrated measurement and monitoring capabilities.
- Compatible with ABB Tmax XT5 moulded case circuit breakers.
- Touch interface simplifies setup, diagnostics and commissioning.
Key Features
- ABB SACE Tmax XT5 accessory.
- Ekip Touch Measuring LSIG electronic trip unit.
- Rated current In = 630 A.
- Three-pole (3P) AC configuration.
- LSIG protection: Long time, Short time, Instantaneous and Ground fault.
- Integrated electrical measurement functionality.
- Touchscreen display for configuration and monitoring.
- Adjustable protection parameters.
- Compatible with ABB low-voltage power distribution systems.
Intelligent Circuit Protection for Modern Electrical Systems
Electronic trip units such as the ABB Ekip Touch Measuring LSIG provide accurate protection coordination and advanced diagnostics for industrial electrical networks. They continuously analyse electrical conditions to help prevent equipment damage and improve system reliability.
The ABB Ekip platform enables engineers to configure protection parameters, monitor operating conditions and optimise low-voltage distribution performance. The 1SDA100605R1 provides a flexible solution for switchboards, machinery power systems and industrial automation applications.
Typical Applications
- Industrial switchgear assemblies.
- Manufacturing and automation power systems.
- Commercial electrical distribution boards.
- Machine protection systems.
- OEM control panels.
- Low-voltage energy management installations.
