Why Choose the Finder 7P.01.8.260.1025 Surge Protection Device?
The Finder 7P.01.8.260.1025 is a compact and reliable Type 1+2 surge protection device (SPD) designed to protect low-voltage electrical installations against transient overvoltages caused by lightning discharge, induced surges and switching events. As part of the Finder 7P Series, it is suitable for use in industrial distribution boards, control panels and electrical switchboards requiring robust surge protection.
This surge arrester uses varistor and GDT protection technology to help limit damaging voltage peaks before they reach sensitive equipment. Its modular DIN rail design supports fast installation and maintenance, while the replaceable protection module helps reduce downtime and simplify servicing in commercial and industrial environments.
With a nominal voltage of 230 V AC, 30 kA nominal discharge current and IP20 protection rating, the Finder 7P.01.8.260.1025 is well suited to 230/400 V systems where reliable surge protection is required for switchboards, automation panels and power distribution equipment.
Key Advantages
- Type 1+2 surge protection device for low-voltage electrical systems.
- 30 kA nominal discharge current for high surge handling capability.
- 230 V AC nominal voltage suitable for common switchboard applications.
- Designed for DIN rail mounting in electrical panels and distribution boards.
- Replaceable protection module supports efficient maintenance.
- Compact 36 mm width helps save space inside control panels.
Key Features
- Finder 7P Series surge protection device.
- Type 1+2 SPD classification.
- 1-pole surge arrester for panel protection applications.
- Nominal voltage 230 V AC.
- Nominal discharge current 30 kA.
- IP20 degree of protection.
- 35 mm DIN rail mounting to EN 60715.
- Operating temperature range from -40 °C to +80 °C.
Reliable Surge Protection for Electrical Switchboards
Surge protection devices help protect electrical installations by diverting transient overvoltages away from connected equipment. This reduces the risk of damage to switchgear, control devices, power supplies, automation components and other sensitive electrical equipment.
The Finder 7P.01.8.260.1025 is designed for installation in low-voltage distribution systems and control panels. Its Type 1+2 classification makes it suitable for protection at the boundary between lightning protection zones, helping safeguard equipment from both high-energy and induced surge events.
Typical Applications
- Electrical distribution boards and switchboards.
- Industrial control panels and automation cabinets.
- Commercial low-voltage installations.
- Machine control and OEM electrical panels.
- Building services and facility power systems.
- Protection of sensitive electrical and electronic equipment.
