Why Choose the Mersen 83120113 Surge Protection Device?
The Mersen 83120113 STPT12-12K150V-2PGM is a dependable Type 1+2 surge protection device (SPD) designed to protect low-voltage electrical installations against lightning currents and transient overvoltages. Part of the Mersen Surge-Trap® Pluggable STPT12 Series, it is suitable for incoming supply panels, main distribution boards and systems requiring first-level surge protection.
This device provides combined protection for single-phase plus neutral systems, using a 1+1 TT configuration with L-N and N-PE protection modes. Its pluggable format allows quick module replacement, while integrated remote indication supports convenient status monitoring.
With a 12.5 kA lightning impulse current (10/350 μs), 120 V nominal operating voltage (Un) and 150 V L-N maximum continuous operating voltage (Uc), the 83120113 provides reliable protection for industrial, commercial and infrastructure electrical installations.
Key Advantages
- Type 1+2 surge protection device for lightning current and transient overvoltage protection.
- 12.5 kA Iimp (10/350 μs) lightning impulse current rating.
- 1Ph+N 1+1 TT configuration for single-phase plus neutral systems.
- 120 V nominal operating voltage with 150 V L-N maximum continuous operating voltage.
- Compact 2-pole pluggable design for DIN rail installation.
- Integrated remote indication for device status monitoring.
Key Features
- Mersen Surge-Trap® STPT12 Series.
- Catalogue number: 83120113.
- Model: STPT12-12K150V-2PGM.
- IEC Type 1+2 / Class I+II surge protection.
- 120 V AC nominal operating voltage (Un).
- 150 V AC maximum continuous operating voltage L-N.
- 2-pole, 2-module pluggable format.
- Remote indication for monitoring.
- DIN rail mounting.
- Designed for 1+1 TT single-phase plus neutral configurations.
Reliable Protection Against Transient Overvoltages
Surge protection devices help protect electrical equipment from damaging voltage spikes caused by lightning activity, switching operations and disturbances on the power network. Installing a Type 1+2 SPD at the incoming supply point helps reduce the risk of equipment damage, downtime and disruption to critical systems.
The Mersen STPT12 Series is engineered for low-voltage distribution applications where reliable surge protection, compact installation and straightforward maintenance are required. The pluggable format allows protection modules to be replaced quickly without rewiring the complete assembly.
Typical Applications
- Main electrical distribution boards.
- Incoming power supply panels.
- Single-phase plus neutral electrical systems.
- Commercial building installations.
- Industrial control panels.
- Infrastructure and critical power systems.
