Mersen Surge Protector Type 2 SPD 2 Pole 120 Volt 20KA TT

Mersen Surge Protector Type 2 SPD 2 Pole 120 Volt 20KA TT

Mersen STPT2-40K150V-2PG Type 2 surge protection device with 40 kA maximum discharge current, 150 V AC Uc, 120 V AC 1Ph+N 1+1 TT configuration and pluggable DIN rail mounting.

SKU: 83020114Alt SKU: STPT2-40K150V-2PGMPN: 83020114
Price
List Price £81.59 ex VAT
Your Price (ex VAT) Save 26%
£60.30 26% OFF
You save £21.29 per unit
Manufacturer Lead Time Please contact us for a delivery time before you order
Get the best trade prices Trade exclusive

Create a trade account to unlock exclusive pricing, special offers and more.

Sign up for a trade account Quick & easy setup
SUBTOTAL (EX VAT) £60.30
Trade pricing is personalised to your account

Manufacturer Lead Time

£60.30

Why Choose the Mersen 83020114 Surge Protection Device?

The Mersen 83020114 is a compact Type 2 surge protection device (SPD) designed to protect low voltage electrical installations from transient overvoltages caused by switching operations, grid disturbances and indirect lightning effects. Part of the Mersen Surge-Trap® Pluggable STPT2 Series, it provides reliable protection for single phase power distribution systems.

The STPT2-40K150V-2PG is designed for 120 V AC 1Ph+N TT systems and provides a 40 kA maximum discharge current (Imax) with a 20 kA nominal discharge current (In). Its 1+1 TT configuration helps protect both line-to-neutral and neutral-to-earth paths, making it suitable for coordinated surge protection in distribution boards and electrical panels.

With a 150 V AC maximum continuous operating voltage (Uc), compact 2 pole, 2 module pluggable design and DIN rail mounting, the Mersen 83020114 is ideal for protecting commercial, industrial and automation systems from damaging voltage surges.

Key Advantages

  • Compact Type 2 surge protection device for low voltage installations.
  • 40 kA maximum discharge current (Imax).
  • 20 kA nominal discharge current (In).
  • 150 V AC maximum continuous operating voltage (Uc).
  • 1+1 TT configuration for 1Ph+N systems.
  • Pluggable module design for quick maintenance and replacement.

Key Features

  • Mersen Surge-Trap® Pluggable STPT2 Series.
  • Type 2 / Class II surge protection.
  • 40 kA Imax (8/20 μs).
  • 20 kA In (8/20 μs).
  • 120 V AC nominal operating voltage.
  • 150 V AC Uc.
  • 1Ph+N, 1+1 TT configuration.
  • 2 pole, 2 module DIN rail mounted design.

Reliable Protection Against Electrical Surges

Type 2 surge protection devices help divert transient overvoltages away from connected electrical equipment, reducing the risk of component damage, nuisance failures and costly downtime. They are commonly used in distribution boards as part of a coordinated low voltage surge protection strategy.

The Mersen Surge-Trap® STPT2 Series combines high surge handling capability with a compact DIN rail format and replaceable pluggable cartridges, making it a practical choice for maintaining reliable electrical protection in demanding installations.

Typical Applications

  • Single phase 120 V TT electrical systems.
  • Commercial distribution boards.
  • Industrial control panels.
  • PLC and automation systems.
  • Building electrical services.
  • Low voltage power distribution equipment.

Technical Specifications

Voltage 120 V
Phase Single Phase
Manufacturer Mersen
Series Surge-Trap® Pluggable STPT2 Series - 40 kA
Model STPT2-40K150V-2PG
SKU 83020114
Product type Type 2 Surge Protection Device
SPD class Type 2 / Class II
Nominal operating voltage 120 V AC
Maximum continuous operating voltage (Uc) 150 V AC
Maximum discharge current (Imax) 40 kA
Nominal Discharge Current (In) 20 kA
Configuration TN-S, TT
Number of poles 2 Poles
Module width 2 Modules
Assembly format Pluggable
Mounting type DIN rail
Remote indication No
Voltage protection level ≤ 1 kV L-N, ≤ 1.5 kV N-PE
Standards EN/IEC 61643-11, UL 1449
Replacement cartridges SP2-40K150V, SP2-40K-N
HS Code 85363090
Country of Manufacture Spain
Poles 2-pole
Device Type Surge protection device
SPD Type Type 2
Earthing System TN-S, TT
Nominal Discharge Current (In) 20 kA
Remote Signal No

Frequently Asked Questions

What is the Mersen 83020114 used for?

It is used to protect low voltage single phase TT electrical systems from transient overvoltages caused by switching operations, grid disturbances and indirect lightning effects.

What type of surge protection device is it?

The Mersen 83020114 is a Type 2 / Class II surge protection device with a pluggable module design.

What voltage is this SPD designed for?

It is designed for 120 V AC 1Ph+N systems with a 150 V AC maximum continuous operating voltage.

What does 1+1 TT mean?

1+1 TT refers to a surge protection configuration used in single phase TT systems, providing protection between line and neutral as well as neutral and protective earth.

Can the protection cartridges be replaced?

Yes. The pluggable design allows the protection cartridges to be replaced quickly when required without replacing the complete surge protection assembly.
