ABB F202 A S-100/0.3 residual current circuit breaker, a 2-pole Type A selective RCCB with 100 A rated current and 300 mA residual operating current for earth leakage protection in electrical installations.
£292.20
The ABB F202 A S-100/0.3 is a selective 2-pole residual current circuit breaker (RCCB) designed to provide dependable earth leakage protection in residential, commercial and industrial electrical installations. Identified by ABB product code 2CSF202201R3900, this device forms part of the trusted ABB F200 RCCB series, widely used for professional residual current protection in distribution boards and switchgear.
This Type A selective RCCB detects alternating residual currents and pulsating DC residual currents, making it suitable for circuits supplying modern electrical and electronic equipment. The selective operating characteristic helps improve discrimination with downstream residual current devices, reducing unnecessary disconnection and supporting continuity of supply.
With a rated current of 100 A and a 300 mA residual operating current, the ABB F202 A S-100/0.3 is ideal for higher-load circuits where selective earth leakage protection and fire protection against insulation faults are required. Its compact DIN rail mounting format allows straightforward installation inside modular electrical enclosures.
Residual current circuit breakers monitor the balance of current flowing through live and neutral conductors. If leakage current to earth creates an imbalance above the trip threshold, the RCCB disconnects the circuit to help reduce the risk of electric shock, insulation damage and electrical fire.
The ABB F202 A S-100/0.3 provides selective residual current protection, helping coordinate with downstream protective devices. This makes it particularly useful in installations where continuity of supply and discrimination between protective levels are important.
| Current | 100 A |
|---|---|
| Manufacturer | ABB |
| Series | F200 |
| Model | F202 A S-100/0.3 |
| Product code | 2CSF202201R3900 |
| EAN | 8012542916109 |
| Product type | Residual Current Circuit Breaker (RCCB) |
| Number of poles | 2 |
| Rated current | 100 A |
| Rated residual operating current | 300 mA |
| Residual current type | Type A |
| Operating characteristic | Selective |
| Rated operational voltage | 277 V AC |
| Typical rated AC voltage | 230 V AC |
| Frequency | 50 / 60 Hz |
| Rated insulation voltage | 500 V |
| Rated impulse withstand voltage | 4 kV |
| Breaking capacity | 1 kA |
| Surge current capacity | 5 kA |
| Standards | IEC/EN 61008, UL 1053 |
| Mounting type | DIN rail |
| Terminal type | Screw terminal |
| Actuator type | Toggle switch |
| Break time | Selective / time delayed |
| Degree of protection | IP2X terminals / IP40 housing |
| Operating temperature | -25 to +55 °C |
| Dimensions (H × W × D) | approx. 85 × 35 × 69 mm |
| Weight | approx. 0.20 kg |
| HS Code | 85363030 |
| Country of Manufacture | Italy |
The ABB F202 A S-100/0.3 is used to provide selective earth leakage protection in electrical installations by disconnecting the circuit when residual current is detected.
This RCCB has a 100 A rated current, making it suitable for higher-load distribution circuits.
The device has a 300 mA rated residual operating current, making it suitable for earth fault and fire protection applications.
A selective RCCB is designed with a delayed operating characteristic to improve coordination with downstream residual current devices and help reduce unnecessary disconnection.
The device is designed for DIN rail mounting inside distribution boards, control panels and modular switchgear assemblies.
ABB F200 residual current circuit breakers are trusted by electricians, panel builders and electrical engineers for dependable earth leakage protection, robust construction and long-term performance in modern electrical installations.
