Why Choose the Partex COL95-16 Copper Tube Ring Terminal?
The Partex COL95-16 is a robust copper tube ring terminal designed for secure electrical cable termination in industrial, commercial and power distribution applications. Suitable for 95 mm² copper conductors and featuring an M16 stud connection, this terminal provides a practical solution for connecting electrical cables to compatible equipment terminals, busbars and bolted electrical connections.
Manufactured from copper, the COL95-16 provides excellent electrical conductivity and is designed to establish a dependable mechanical and electrical connection when installed using suitable crimping equipment. Its tubular barrel accommodates the prepared conductor, while the ring-shaped connection palm allows the terminal to be securely fastened to a compatible M16 stud or bolted connection point.
Designed for 95 mm² electrical cables and M16 mounting studs, the Partex COL95-16 is supplied in a convenient pack of 50 terminals. This makes it suitable for electrical contractors, panel builders, maintenance engineers and industrial installers requiring consistent cable termination across multiple electrical connections.
Key Advantages
- Reliable copper tube ring terminal for secure electrical cable termination.
- 95 mm² conductor compatibility for industrial electrical power connections.
- M16 stud connection for compatible bolted electrical terminals.
- Copper construction provides excellent electrical conductivity.
- Ring-shaped connection helps maintain secure fastening when correctly installed.
- Designed for crimp termination using suitable cable crimping tools.
- Tubular barrel construction supports effective conductor insertion and crimping.
- Suitable for electrical distribution equipment, switchgear and industrial machinery.
- Provides a practical termination solution for larger copper power conductors.
- Suitable for professional electrical installation, cable replacement and maintenance.
- Supplied in a pack of 50 terminals for efficient installation and maintenance work.
Key Features
- Partex COL copper tube terminal range.
- 95 mm² nominal conductor cross-section.
- M16 stud size.
- Copper terminal construction.
- Ring-type connection for stud and bolted fastening.
- Tubular conductor barrel for crimp termination.
- Designed for use with compatible copper conductors.
- Suitable for electrical panel building and industrial power wiring.
- Designed to provide a permanent crimp connection when correctly installed.
- Suitable for equipment connections requiring an M16 mounting point.
- 50 terminals per pack.
Secure Electrical Connections for Industrial Power Distribution
Copper tube ring terminals are commonly used to terminate electrical conductors where a reliable bolted connection is required. The Partex COL95-16 is designed to connect a 95 mm² copper conductor to an electrical terminal fitted with an M16 stud or compatible fastening.
The tubular copper construction provides a suitable barrel for crimping the conductor, while the ring-shaped connection palm allows the completed termination to be secured beneath a compatible fastening. This arrangement is useful in electrical distribution equipment, industrial control cabinets, switchgear assemblies and machinery where secure cable connections are essential.
For larger conductor sizes such as 95 mm², correct cable preparation and termination are particularly important. The terminal must be matched to the conductor construction and the appropriate crimping system to achieve effective electrical contact and mechanical retention. Suitable cable support also helps minimise stress at the connection point.
During installation, the prepared conductor is inserted into the tubular barrel and secured using an appropriately sized crimping tool and die. A correctly formed crimp provides mechanical retention and effective electrical contact between the conductor and terminal. The ring end is then fastened to the equipment connection point using the specified tightening procedure.
The COL95-16 provides a practical cable termination solution for electrical contractors, panel manufacturers and maintenance personnel. Correct conductor preparation, compatible crimping equipment, appropriate fastening torque and suitable cable support are essential for achieving a dependable electrical connection. The M16 mounting point must also be electrically and mechanically suitable for the intended conductor and load.
Typical Applications
- Electrical distribution boards and switchgear assemblies.
- Industrial control panels and electrical cabinets.
- Electrical equipment terminal connections.
- Compatible busbar and bolted terminal connections.
- Industrial machinery and electrical power connections.
- Power distribution and electrical installation projects.
- Electrical infrastructure and industrial equipment installations.
- Equipment maintenance and cable replacement.
- Panel building and electrical assembly production.
- Commercial and industrial electrical installations.
- Electrical systems requiring 95 mm² conductors with M16 stud connections.
