TE Connectivity 1SNA094364R2600 CPFT2/R-14 is a 14-pole 5.08 mm pitch female pluggable terminal connector with perpendicular wire entry and screw-clamp termination, rated at 250 V and 12 A to IEC specifications.
£9.92
The TE Connectivity 1SNA094364R2600, also identified as CPFT2/R-14, is a 14-pole female pluggable terminal connector from the Entrelec CPFT2/R range, designed for reliable multi-circuit connections in industrial control, automation and PCB interface applications. Its screw-clamp termination and perpendicular wire-entry configuration provide a compact, serviceable connection between field wiring and compatible electrical equipment.
The CPFT2/R series is designed with conductors entering perpendicular to the connector insertion axis, making it particularly useful where control-panel layout or cable routing favours right-angle wire entry. The CPFT2/R-14 uses a 5.08 mm pitch, black insulating housing and screw connection technology to provide secure termination for industrial control and signal wiring.
With 14 poles and an overall connector length of approximately 71.04 mm, the CPFT2/R-14 provides a compact multi-circuit interface. The connector is rated at 250 V and 12 A to IEC specifications and 300 V and 15 A under UL specifications, with conductor compatibility up to 2.5 mm² / 12 AWG.
Pluggable terminal connectors provide a practical interface between field wiring and electrical or electronic equipment. Conductors remain securely terminated in the removable plug, allowing connected equipment to be disconnected for installation, servicing or replacement without repeatedly disturbing each individual wire termination.
The CPFT2/R-14 combines 14 connection circuits with perpendicular wire entry, making it particularly suitable for installations where cables need to approach the connector at a right angle to its mating direction. Its 5.08 mm pitch, industrial electrical ratings and screw-clamp technology make it a versatile connection solution for automation panels, machinery and PCB-based control equipment.
| Manufacturer | TE Connectivity / Entrelec |
|---|---|
| Series | CPFT2/R |
| Model | CPFT2/R-14 |
| Manufacturer part number | 1SNA094364R2600 |
| Product type | Female pluggable terminal connector |
| Number of poles | 14 |
| Connector gender | Female |
| Connection technology | Screw clamp |
| Wire-entry orientation | Perpendicular to insertion axis |
| Pitch | 5.08 mm |
| Connector length | approx. 71.04 mm |
| Body colour | Black |
| IEC conductor capacity | Up to 2.5 mm² |
| UL conductor range | 24–12 AWG |
| IEC rated voltage | 250 V |
| IEC rated current | 12 A |
| UL rated voltage | 300 V |
| UL rated current | 15 A |
| Nominal conductor size | 2.5 mm² / 12 AWG |
| Material | Polyamide |
| Pack quantity | 10 |
| EAN | 3472590943642 |
The 1SNA094364R2600 is a 14-pole CPFT2/R female pluggable terminal connector with perpendicular wire entry and screw-clamp termination for industrial electrical, automation and PCB interface applications.
The CPFT2/R-14 provides 14 connection poles arranged on a 5.08 mm pitch.
The CPFT2/R design routes connected wires perpendicular to the connector insertion axis, providing convenient right-angle cable routing in compatible installations.
The connector is rated at 250 V and 12 A to IEC specifications and 300 V and 15 A under UL specifications.
The connector is designed for conductors up to 2.5 mm², with a UL conductor range of 24–12 AWG.
TE Connectivity and Entrelec CPFT2 pluggable connection components provide compact, serviceable interfaces for industrial automation and control equipment, combining secure screw-clamp wiring with convenient removable multi-pole connectivity.
