Why Choose the TE Connectivity M4/6 V0 Beige 1SNA195116R0000 Terminal Block?
The TE Connectivity Terminal Block M4/6 V0 Beige 1SNA195116R0000 is a compact feed-through screw-clamp terminal block from the Entrelec SNA range. Designed for signal and general industrial wiring, the M4/6 provides a secure, serviceable connection between two conductors while occupying only 6 mm of DIN rail width.
The 1SNA195116R0000 is rated at 32 A and 1000 V to IEC specifications, with a nominal conductor size of 4 mm². Its screw-clamp terminals accommodate flexible conductors from 0.22–4 mm² and rigid stranded conductors from 0.2–4 mm², making it a versatile connection point for industrial control-panel wiring.
Manufactured with a beige Polyamide 6.6 housing, the M4/6 provides IP20 protection and a UL 94 V-0 flammability rating. Compatibility with G32, TH35-7.5 and TH35-15 DIN rails allows the terminal to be incorporated into a wide variety of new and existing Entrelec terminal assemblies.
Key Advantages
- Compact 6 mm wide feed-through terminal for space-efficient panel wiring.
- 32 A IEC current rating for industrial signal and control circuits.
- 1000 V IEC voltage rating with an 8 kV impulse withstand rating.
- Supports conductors up to 4 mm².
- Proven screw-clamp termination provides secure and serviceable connections.
- Compatible with G32 and TH35 DIN rails for flexible installation.
Key Features
- TE Connectivity / Entrelec SNA modular terminal block.
- M4/6 feed-through configuration.
- 2 positions, 2 poles and 1 circuit.
- Single-level construction.
- 6 mm spacing.
- 4 mm² nominal wire size.
- Beige Polyamide 6.6 housing.
- IP20 protection at the main terminals.
- UL 94 V-0 flammability rating.
- Operating temperature range from -55 to +110 °C.
Reliable Feed-Through Connections for Industrial Panels
Feed-through terminal blocks provide an organised method of joining incoming and outgoing conductors while keeping individual circuits accessible for inspection and maintenance. The M4/6 uses established screw-clamp technology to maintain a secure mechanical and electrical connection in industrial control, signal and automation wiring.
With its 32 A IEC current rating, 1000 V IEC voltage rating and compact 6 mm profile, the 1SNA195116R0000 combines useful electrical capacity with efficient DIN rail utilisation. Multiple rail compatibility also makes it a practical choice for both new installations and maintenance of existing Entrelec SNA terminal assemblies.
Typical Applications
- Industrial control-panel wiring.
- Signal and instrumentation circuits.
- Machine and factory automation systems.
- Switchgear and electrical distribution cabinets.
- DIN rail terminal block assemblies.
- OEM machinery and equipment wiring.
