Why Choose the TE Connectivity 1SNA195120R1000 M10/10.V0 Beige Terminal Block?
The TE Connectivity 1SNA195120R1000 is an M10/10.V0 beige feed-through screw-clamp terminal block from the Entrelec SNA range. Designed for reliable conductor termination on DIN rail assemblies, it provides two connection positions on a single level and is suitable for industrial control, signal and distribution wiring.
With a 10 mm spacing, the M10/10.V0 accepts flexible conductors from 0.5–10 mm² and rigid stranded conductors from 0.5–16 mm². Its IEC ratings include a 57 A rated current and 1000 V rated voltage, providing substantial electrical capability in a compact terminal format.
The terminal uses a durable polyamide 6.6 housing with a UL 94V-0 flammability rating and IP20 protection. Compatible with G32, TH35-7.5 and TH35-15 mounting rails, the 1SNA195120R1000 offers a versatile solution for new panel construction, machinery and maintenance of established Entrelec SNA installations.
Key Advantages
- 57 A IEC current rating supports demanding industrial terminal connections.
- 1000 V IEC voltage rating provides high electrical capacity for compatible applications.
- Accepts rigid stranded conductors up to 16 mm² and flexible conductors up to 10 mm².
- Screw-clamp termination provides a secure and serviceable conductor connection.
- IP20 protection helps reduce accidental contact with conductive terminal parts.
- Compatible with G32 and TH35 DIN rail formats for flexible panel installation.
Key Features
- TE Connectivity / Entrelec M10/10.V0 feed-through terminal block.
- 2 positions with one electrical circuit and one connection level.
- 10 mm terminal spacing.
- Beige polyamide 6.6 housing.
- 57 A / 1000 V IEC ratings.
- 65 A UL and 70 A CSA current ratings.
- UL 94V-0 housing flammability rating.
- Wide -55 to +110 °C operating temperature range.
Reliable Screw-Clamp Feed-Through Connections
The M10/10.V0 provides a straightforward feed-through connection for joining incoming and outgoing conductors within a DIN rail terminal assembly. Its screw-clamp termination delivers a mechanically secure connection while remaining accessible for inspection, testing and maintenance, making it well suited to professional control-panel and machine-building applications.
A 10 mm-wide modular format allows multiple terminals to be installed in an organised row, while compatibility with G32 and both common TH35 rail depths provides installation flexibility. The polyamide 6.6 housing, IP20 construction and broad operating temperature range further support reliable use in demanding industrial electrical environments.
Typical Applications
- Industrial electrical control panels.
- Signal and control circuit connections.
- Factory automation equipment.
- Machine-building electrical systems.
- Switchgear and distribution assemblies.
- Maintenance and refurbishment of Entrelec SNA terminal installations.
