Why Choose the TE Connectivity MA2.5/5.V0 Beige Terminal Block?
The TE Connectivity MA2.5/5.V0 is a compact screw-clamp feed-through terminal block designed for reliable electrical connections in industrial control panels, automation systems and signal wiring applications. Part of the established ENTRELEC SNA terminal block range, it combines a space-saving 5 mm pitch with secure screw termination for efficient DIN rail wiring.
The MA2.5/5.V0 features 2 positions on a single level and accommodates conductors up to 2.5 mm² as its rated cross-section. The screw-clamp connection provides dependable conductor retention, while the compact 5 mm width helps maximise terminal density within electrical cabinets.
With a 24 A IEC current rating, 1000 V IEC voltage rating and 8 kV impulse withstand voltage, the 1SNA195486R0400 is suitable for demanding industrial signal and control applications. Its beige polyamide 6.6 housing has a UL 94 V-0 flammability rating and provides IP20 protection at the main terminals.
Key Advantages
- Compact feed-through screw-clamp terminal block for industrial wiring.
- 24 A IEC rated current for suitable signal and control circuits.
- 1000 V IEC rated voltage for industrial electrical applications.
- 5 mm terminal spacing helps maximise DIN rail space.
- Accommodates conductors up to 2.5 mm².
- 8 kV impulse withstand voltage provides high insulation performance.
- UL 94 V-0 polyamide 6.6 housing supports demanding industrial installations.
- Suitable for G32, TH35-7.5 and TH35-15 DIN rails.
Key Features
- TE Connectivity ENTRELEC SNA terminal block range.
- MA2.5/5.V0 feed-through terminal block.
- 2-position single-level configuration.
- 5 mm terminal spacing.
- 2.5 mm² rated cross-section.
- 24 A IEC rated current.
- 1000 V IEC rated voltage.
- 8 kV IEC impulse withstand voltage.
- Screw-clamp connection technology.
- Beige polyamide 6.6 insulating housing.
- UL 94 V-0 flammability rating.
- IP20 protection at the main terminals.
Compact and Reliable DIN Rail Wiring
Feed-through terminal blocks provide an organised method of joining incoming and outgoing conductors within electrical control panels. The MA2.5/5.V0 uses screw-clamp technology to provide a secure electrical connection while maintaining a compact 5 mm terminal pitch.
The slim 5 mm profile allows high terminal density on G32 and 35 mm DIN rail systems, making the terminal block particularly useful where cabinet space is limited. The beige polyamide 6.6 housing, UL 94 V-0 flammability rating and IP20 main-terminal protection support its use in industrial control and signal applications.
Typical Applications
- Industrial electrical control panels.
- PLC and automation control systems.
- Signal and instrumentation circuits.
- Machine control cabinets.
- High-density DIN rail wiring assemblies.
- Industrial electrical distribution and control equipment.
