Why Choose the TE Connectivity D6/8.ADO Orange Terminal Block?
The TE Connectivity D6/8.ADO is a compact feed-through ADO/Screw terminal block designed for reliable electrical connections in industrial control panels, automation systems and instrumentation applications. Identified by manufacturer part number 1SNA199043R2600, this orange terminal block combines the TE Connectivity ADO System connection technology with a conventional screw-clamp connection.
As part of the TE Connectivity Entrelec SNA ADO terminal block range, the D6/8.ADO provides the benefits of fast ADO insulation-displacement connection while allowing connection to standard screw-clamp wiring. The design helps simplify panel assembly and provides a dependable solution for modular DIN rail wiring.
The D6/8.ADO has an 8 mm spacing, a 24 A rated current and a 1000 V rated voltage. It accepts 1–2.5 mm² conductors through the ADO connection and supports larger conductors through the screw-clamp connection, making it suitable for a wide range of industrial electrical installations.
Key Advantages
- Compact feed-through ADO/Screw terminal block for industrial electrical installations.
- ADO System connection technology provides fast insulation-displacement termination.
- 24 A rated current for suitable industrial control and distribution circuits.
- 1000 V rated voltage for demanding electrical panel applications.
- 8 mm spacing provides a practical balance between conductor capacity and panel density.
- Flexible connection arrangement combining ADO and screw-clamp technologies.
- Orange housing provides clear visual identification within terminal block assemblies.
Key Features
- TE Connectivity Entrelec SNA ADO terminal block.
- D6/8.ADO feed-through configuration.
- ADO System and screw-clamp connections.
- 24 A rated current.
- 1000 V rated voltage.
- 8 mm spacing.
- Orange insulation housing.
- Manufacturer part number 1SNA199043R2600.
- ADO connection for 1–2.5 mm² conductors.
- Screw-clamp connection for flexible conductors from 0.22–6 mm² and rigid conductors from 0.2–10 mm².
- IP20 protection at the main terminals.
- DIN rail mounting on TH35-7.5 and TH35-15 rails.
Fast and Flexible ADO/Screw Terminal Connections
The TE Connectivity D6/8.ADO combines ADO System technology with a standard screw-clamp connection, allowing installers to benefit from rapid ADO termination while retaining compatibility with conventional wiring. The ADO System can accept up to two wires per connection and helps reduce the need for repeated tightening associated with conventional terminal connections.
The terminal block is designed for DIN rail installation and provides 8 mm spacing, making it suitable for organised control cabinet wiring. Its asymmetrical design helps reduce mounting and wiring errors, while the orange housing provides straightforward visual identification within larger terminal block assemblies.
Typical Applications
- Industrial electrical control panels.
- Machine building and industrial automation.
- Process control and instrumentation systems.
- Electrical switchgear and control cabinets.
- DIN rail wiring and distribution systems.
- Industrial machine control equipment.
- Applications requiring a transition between ADO and standard screw-clamp wiring.
