Why Choose the TE Connectivity 1SNA199044R2700 D6/8 N.ADO Terminal Block?
The TE Connectivity 1SNA199044R2700 is a blue D6/8 N.ADO feed-through terminal block combining an ADO insulation displacement connection with a conventional screw clamp. Part of the established TE Connectivity ENTRELEC SNA ADO series, it provides a flexible and reliable wiring solution for industrial control panels, machinery and electrical distribution systems.
The D6/8 N.ADO combines the speed of the ADO connection system with the versatility of screw-clamp termination. The ADO connection allows conductors to be terminated efficiently without conventional wire stripping, while the screw connection provides a familiar termination method on the opposite side. This hybrid design is particularly useful for panel builders seeking efficient installation while retaining compatibility with traditional wiring practices.
Rated at 24 A with a voltage rating of up to 1000 V, the 1SNA199044R2700 is designed for demanding industrial electrical applications. Its 8 mm width, blue insulating body and DIN rail mounting format make it particularly suitable for neutral conductor circuits and space-efficient control cabinet installations.
Key Advantages
- Hybrid ADO insulation displacement and screw-clamp connection technology.
- 24 A rated current for industrial control and distribution circuits.
- Voltage rating of up to 1000 V.
- Blue body provides convenient identification for neutral conductor applications.
- Compact 8 mm terminal spacing supports efficient panel layouts.
- DIN rail mounting enables straightforward integration into industrial electrical cabinets.
Key Features
- TE Connectivity ENTRELEC SNA ADO series.
- ADO / screw feed-through terminal block.
- 24 A rated current.
- 1000 V rated voltage.
- 8 mm width.
- IP20 protection rating at the main terminals.
- Blue thermoplastic insulating body.
- Operating temperature range of -55 to +110 °C.
- Compatible with TH35-7.5 and TH35-15 DIN rails.
Reliable ADO and Screw Connection Technology
The TE Connectivity ENTRELEC ADO system is designed to simplify industrial wiring by using insulation displacement technology to establish a reliable electrical connection. By combining this technology with a conventional screw clamp, the D6/8 N.ADO provides flexibility for installations where different conductor termination methods are required within the same circuit.
The terminal block mounts on standard 35 mm DIN rail and has a compact 8 mm profile, making it suitable for densely populated electrical enclosures. Its blue colour allows straightforward identification within neutral circuits, while its industrial temperature range and IP20 terminal protection support dependable operation in demanding control and automation environments.
Typical Applications
- Neutral conductor connections in industrial control panels.
- Machine building and factory automation systems.
- Electrical distribution and switchgear assemblies.
- PLC and automation control cabinets.
- DIN rail wiring and marshalling systems.
- OEM machinery and industrial equipment.
