1sna199072r2300 - d6/8.ado yellow terminal block [pk=50]

1sna199072r2300 – d6/8.ado yellow terminal block [pk=50]

TE Connectivity 1SNA199072R2300 D6/8.ADO is a yellow 24 A, 1000 V feed-through DIN rail terminal block combining ADO System and screw-clamp connection technology for industrial control and automation wiring.

SKU: 1SNA199072R2300Alt SKU: D6/8.ADO Yellow Terminal Block [pk=50]MPN: 1SNA199072R2300
Price on application Contact us for pricing and availability.
Call 01708 343600

Why Choose the TE Connectivity 1SNA199072R2300 D6/8.ADO Yellow Terminal Block?

The TE Connectivity 1SNA199072R2300 is a yellow D6/8.ADO feed-through terminal block designed for reliable conductor termination in industrial control panels, machinery and electrical distribution systems. Part of the established TE Connectivity ENTRELEC ADO terminal block range, it combines ADO insulation displacement connection technology with a conventional screw clamp for flexible industrial wiring.

The D6/8.ADO provides the installation benefits of the ADO System while allowing connection using a standard screw clamp on the opposite side. This hybrid connection arrangement enables efficient panel wiring while retaining the versatility of conventional screw termination, making it particularly useful for machine builders, control panel manufacturers and industrial automation engineers.

With a rated current of 24 A and rated voltage of 1000 V, the 1SNA199072R2300 is suitable for demanding industrial circuits. Its compact 8 mm width, yellow polyamide insulating body and compatibility with standard 35 mm DIN rail systems make it a practical solution for space-efficient electrical cabinet installations.

Key Advantages

  • Hybrid ADO insulation displacement and screw-clamp connection technology.
  • 24 A rated current for industrial control and distribution circuits.
  • 1000 V rated voltage for demanding electrical applications.
  • Compact 8 mm terminal spacing supports space-efficient panel layouts.
  • IP20 protection at the main terminals.
  • Yellow identification colour simplifies circuit organisation within control cabinets.

Key Features

  • TE Connectivity ENTRELEC D6/8.ADO terminal block.
  • Feed-through ADO / screw-clamp configuration.
  • 24 A rated current.
  • 1000 V rated voltage.
  • 2.5 mm² rated cross-section.
  • Screw-clamp conductor capacity up to 10 mm² rigid or 6 mm² flexible.
  • 8 mm spacing for compact terminal assemblies.
  • IP20 main terminal protection.
  • Wide operating temperature range of -55 to +110 °C.
  • Supplied in manufacturer packs of 50 pieces.

Reliable ADO Connection Technology for Industrial Wiring

The ENTRELEC ADO System is designed to provide fast and dependable conductor termination for industrial wiring applications. The D6/8.ADO combines the ADO connection system with a standard screw clamp, allowing installers to take advantage of efficient ADO termination while maintaining compatibility with conventional screw-connected conductors.

The terminal block mounts on standard TH35-7.5 and TH35-15 DIN rails and has an 8 mm spacing, making it suitable for densely populated control cabinets. Its polyamide construction, UL94 V0 flammability rating and broad operating temperature range support dependable performance in demanding industrial automation and electrical distribution environments.

Typical Applications

  • Industrial control panels and electrical cabinets.
  • Machine building and factory automation systems.
  • Electrical distribution and switchgear assemblies.
  • PLC and automation control cabinets.
  • DIN rail wiring and marshalling systems.
  • OEM machinery and industrial equipment.

Technical Specifications

Tick the specs you need, then view products that match.

Number of Levels 1
Connection IDC (ADO)
Terminal Type Multi-level
Conductor Size 2.5 mm²
Product Series TE SNA ADO
Manufacturer TE Connectivity / ENTRELEC
Series ADO System
Model D6/8.ADO
Manufacturer part number 1SNA199072R2300
Product type IDC feed-through terminal block
Function Feed-through
Connection type Screw clamp / ADO System
Rated current 24 A
Rated voltage 1000 V
Maximum operating voltage UL/CSA 600 V
Rated impulse withstand voltage 8000 V
Rated cross-section 2.5 mm²
Screw-clamp flexible conductor capacity 0.22–6 mm²
Screw-clamp rigid conductor capacity 0.2–10 mm²
Number of levels 1
Colour Yellow
Insulation material Polyamide
Flammability rating UL94 V0
Protection rating IP20 at main terminals
Mounting type TH35-7.5 / TH35-15 DIN rail
Spacing 8 mm
Dimensions (H × W × D) 45 × 8 × 41 mm
Operating temperature -55 to +110 °C
Storage temperature -55 to +110 °C
Dielectric test voltage 3500 V
Rated short-time withstand current 300 A for 1 s
Pollution degree 3
Wire stripping length 12 mm
Weight approx. 11 g
Pack quantity 50
EAN 3472591990720
Colour Yellow

Frequently Asked Questions

What is the TE Connectivity 1SNA199072R2300 used for?

The 1SNA199072R2300 D6/8.ADO is a feed-through DIN rail terminal block designed for reliable conductor connections in industrial control panels, machinery, electrical distribution and automation systems.

What is the current rating of the D6/8.ADO terminal block?

The D6/8.ADO has a rated main circuit current of 24 A.

What voltage is the 1SNA199072R2300 rated for?

The terminal block has a rated voltage of 1000 V, with a maximum UL/CSA operating voltage of 600 V.

What type of connection does the D6/8.ADO use?

The D6/8.ADO combines an ADO System connection with a conventional screw clamp, providing flexible termination options for industrial wiring.

How is the TE Connectivity 1SNA199072R2300 supplied?

The yellow D6/8.ADO terminal block is supplied in manufacturer packs of 50 pieces and is designed for mounting on TH35-7.5 or TH35-15 DIN rail.

Trusted Connection Technology for Industrial Systems

TE Connectivity ENTRELEC ADO terminal blocks combine efficient conductor termination with robust industrial construction, providing dependable and space-efficient electrical connections for control panels, machinery and automation systems.
