TE Connectivity 1SNA290221R0400 DS2.5/5.2L is a grey SNA Miniblocks single-level spring-clamp feed-through terminal block rated at 24 A and 800 V with a 2.5 mm² rated cross-section and compact 5 mm pitch for TH35 DIN-rail installations.
£1.02
The TE Connectivity / Entrelec DS2.5/5.2L 1SNA290221R0400 is a compact grey spring-clamp feed-through terminal block from the SNA Miniblocks range, designed for reliable conductor connection in industrial control panels and automation equipment. Its single-level design provides two connection points with a compact 5 mm pitch.
The DS2.5/5.2L uses spring-clamp technology to provide consistent contact pressure independently of operator tightening. Front conductor entry improves accessibility during wiring, while the compact angled housing helps save valuable DIN-rail space in densely populated electrical panels.
Rated at 24 A and 800 V under IEC specifications, the terminal block has a rated cross-section of 2.5 mm² and accepts rigid conductors from 0.12–4 mm². It mounts on standard TH35 DIN rail, features IP20 protection at the main terminals and uses V0-rated thermoplastic insulation.
The DS2.5/5.2L combines a compact angled housing with spring-clamp conductor termination, making it particularly suitable for control panels where installation space and wiring accessibility are important. Spring contact pressure is maintained independently of the installer, with automatic compensation helping preserve a dependable electrical connection over time.
Mounting on standard TH35 DIN rail allows straightforward integration into conventional industrial terminal assemblies. With a 5 mm pitch, two feed-through connections and front conductor entry, the 1SNA290221R0400 provides a practical solution for signal, control and power wiring within its specified electrical ratings.
| Manufacturer | TE Connectivity / Entrelec |
|---|---|
| Series | SNA Miniblocks |
| Type | DS2.5/5.2L |
| Manufacturer part number | 1SNA290221R0400 |
| Product type | Spring-clamp feed-through terminal block |
| Number of levels | 1 |
| Connections per level | 2 |
| Rated cross-section | 2.5 mm² |
| Rigid conductor capacity | 0.12–4 mm² |
| Flexible conductor capacity without ferrule | 0.12–2.5 mm² |
| Rated current | 24 A |
| Rated voltage | 800 V |
| Rated impulse withstand voltage | 8 kV |
| Pitch / width | 5 mm |
| Height | 38 mm |
| Depth | 24.5 mm |
| Mounting | TH35-7.5 / TH35-15 DIN rail |
| Colour | Grey |
| Insulating material | Thermoplastic |
| Flammability classification | UL 94 V0 |
| Degree of protection | IP20 at main terminals |
| Operating temperature | -55 to +110 °C |
| Wire stripping length | 9.5 mm |
| Net weight | approx. 4 g |
| EAN | 3472592902210 |
The 1SNA290221R0400 is the DS2.5/5.2L, a grey single-level spring-clamp feed-through terminal block from the Entrelec SNA Miniblocks range.
The DS2.5/5.2L has an IEC rated current of 24 A and a rated voltage of 800 V.
The terminal block has a rated cross-section of 2.5 mm², accepts rigid conductors from 0.12–4 mm² and flexible conductors without ferrules from 0.12–2.5 mm².
The terminal block is designed for mounting on standard TH35-7.5 or TH35-15 DIN rail.
The terminal block is approximately 5 mm wide, 38 mm high and 24.5 mm deep, providing a compact 5 mm pitch for space-efficient terminal assemblies.
TE Connectivity and Entrelec SNA spring terminal blocks provide panel builders, automation engineers and electrical installers with compact, accessible and dependable conductor connections for professional industrial control and distribution assemblies.
