TE Connectivity / Entrelec D95/26.N 1SNA400371R1100 is a blue 95 mm², 232 A, 1000 V screw clamp feed-through DIN rail terminal block designed for high-current industrial power connections.
£26.77
The TE Connectivity / Entrelec D95/26.N 1SNA400371R1100 is a heavy-duty 95 mm² screw clamp feed-through DIN rail terminal block designed for high-current power connections in industrial control panels, switchgear and electrical distribution systems. Part of the Entrelec terminal block range, it combines substantial conductor capacity with a secure screw terminal connection for dependable industrial power distribution.
The D95/26.N uses a robust screw clamp termination system to provide secure mechanical retention and reliable electrical contact for large conductors. Its single-level feed-through configuration is housed in durable Polyamide 6.6, while the distinctive blue housing allows straightforward identification within complex terminal assemblies.
With an IEC rated current of 232 A and rated voltage of 1000 V AC, the D95/26.N is engineered for demanding high-power circuits. It has a nominal conductor size of 95 mm² / 4/0 AWG, accepts rigid stranded conductors from 35–120 mm² and flexible conductors from 35–95 mm², and mounts on standard TH35 DIN rails.
High-capacity feed-through terminal blocks provide secure connection points for large conductors carrying substantial electrical loads. The screw clamp system mechanically secures each conductor to maintain stable electrical contact, making this type of terminal particularly suitable for power distribution, switchgear and heavy industrial equipment.
The D95/26.N combines a 232 A IEC current rating with conductor capacity up to 120 mm² for rigid stranded cable. Its robust Polyamide 6.6 construction, wide operating temperature range and standard DIN rail mounting make it a practical solution for high-current electrical installations requiring dependable and serviceable connections.
| Manufacturer | TE Connectivity / Entrelec |
|---|---|
| Model | D95/26.N |
| Manufacturer part number | 1SNA400371R1100 |
| Product type | Screw clamp terminal block |
| Block function | Feed-through |
| Circuit application | Power |
| Number of circuits | 1 |
| Number of poles | 2 |
| Number of levels | 1 |
| Number of positions | 6 |
| Gauge type | B12 |
| Nominal wire size | 95 mm² / 4/0 AWG |
| Rated voltage (IEC) | 1000 V |
| Rated current (IEC) | 232 A |
| Rated voltage (UL / CSA) | 600 V |
| Rated current (UL / CSA) | 230 A |
| Operating voltage | 1000 V AC |
| Impulse withstand voltage (IEC) | 8000 V |
| Short-time withstand current at 1 s | 11,400 A |
| Rigid stranded conductor range | 35–120 mm² / 2–4/0 AWG |
| Flexible conductor range | 35–95 mm² |
| Wire stripping length | 26 mm |
| Tool size | 6 mm |
| Termination method | Screw terminal |
| Tightening torque | 9 Nm |
| Housing material | Polyamide 6.6 |
| Colour | Blue |
| Protection rating | IP10 |
| UL flammability rating | UL 94V-0 |
| DIN rail mounting | TH35-7.5 / TH35-15 |
| Product spacing | 26 mm |
| Dimensions (H × W × D) | 87 × 26 × 72 mm |
| Weight | 215 g |
| Installation temperature | -5 to +40 °C |
| Operating temperature | -55 to +110 °C |
The D95/26.N is a heavy-duty feed-through DIN rail terminal block designed to connect large conductors in high-current industrial power distribution, switchgear and machinery applications.
The D95/26.N has an IEC rated current of 232 A and an IEC rated voltage of 1000 V, with a short-time withstand current of 11,400 A for 1 s.
The terminal accepts rigid stranded conductors from 35–120 mm² and flexible conductors from 35–95 mm², with a nominal conductor size of 95 mm² / 4/0 AWG.
The specified tightening torque is 9 Nm, providing a secure screw clamp connection for large power conductors.
The D95/26.N is designed for mounting on TH35-7.5 and TH35-15 DIN rails, making it suitable for standard industrial electrical panel and switchgear installations.
TE Connectivity / Entrelec high-current screw clamp terminal blocks provide robust and dependable conductor connections for panel builders, switchgear manufacturers and industrial engineers requiring reliable power distribution in demanding electrical installations.
