TE Connectivity ZS4-OR 1SNK505030R0000 is an orange 4 mm²-class screw-clamp feed-through DIN-rail terminal block rated at 32 A and up to 1000 V AC/DC IEC, supplied in a pack of 50.
£0.96
The TE Connectivity ZS4-OR 1SNK505030R0000 is a compact and dependable orange screw-clamp feed-through terminal block designed for secure conductor connections in industrial control panels, switchgear and automation equipment. Part of the TE Connectivity ENTRELEC SNK ZS series, it combines proven screw-clamp technology with a space-efficient DIN-rail format for professional electrical installations.
The ZS4-OR is a single-level feed-through terminal with two connection positions, providing a straightforward method of joining incoming and outgoing conductors. Its orange polyamide housing enables clear visual identification and colour coding within terminal assemblies, helping simplify installation, commissioning, troubleshooting and maintenance.
Designed for conductors up to 4 mm², the ZS4-OR provides an IEC rated current of 32 A and supports applications rated up to 1000 V AC/DC IEC. Its narrow 5.2 mm spacing allows high-density terminal arrangements while compatibility with standard TH35 DIN rails simplifies integration into industrial electrical cabinets.
Feed-through terminal blocks provide an organised and serviceable method of connecting conductors inside electrical cabinets. The TE Connectivity ZS4-OR uses a conventional screw-clamp mechanism to establish a secure conductor connection while allowing straightforward installation, inspection and maintenance using standard panel-building tools.
The compact SNK-series design accommodates conductors up to 4 mm² within just 5.2 mm of DIN-rail width. Combined with the orange housing and extensive SNK accessory system, this makes the ZS4-OR well suited to structured, colour-coded terminal assemblies in modern industrial equipment.
| Manufacturer | TE Connectivity |
|---|---|
| Brand / family | ENTRELEC |
| Series | SNK ZS |
| Model | ZS4-OR |
| Part number | 1SNK505030R0000 |
| Product type | Screw-clamp terminal block |
| Block function | Feed-through |
| Terminal size | 4 mm² class |
| Connection type | Screw clamp |
| Colour | Orange |
| Number of positions | 2 |
| Number of circuits | 1 |
| Number of levels | 1 |
| IEC rated current | 32 A |
| IEC rated voltage | 1000 V AC/DC |
| Impulse withstand voltage | 8000 V |
| UL / CSA maximum operating voltage | 600 V |
| Power loss | 1 W |
| Flexible conductor capacity | 0.22–4 mm² |
| Rigid stranded conductor capacity | 0.2–4 mm² |
| Insulated ferrule capacity | 0.22–2.5 mm² |
| Non-insulated ferrule capacity | 0.22–4 mm² |
| Two flexible conductors per clamp | 0.2–1.5 mm² |
| Twin ferrule capacity | 0.22–1.5 mm² |
| Wire stripping length | 10.5 mm |
| Product spacing / width | 5.2 mm |
| Product height | 53 mm |
| Product length | 47.3 mm |
| Housing material | Polyamide |
| DIN rail mounting | TH35-7.5 / TH35-15 |
| Protection rating | IP20 |
| Flammability rating | UL 94V-0 |
| Operating temperature | -55 to +110 °C |
| Installation temperature | -5 to +40 °C |
| Product weight | 8.8 g |
| Pack quantity | 50 |
It is a feed-through DIN-rail terminal block designed to provide secure conductor connections in industrial control panels, automation equipment, switchgear and electrical distribution systems.
The terminal accommodates rigid stranded conductors from 0.2–4 mm² and flexible conductors from 0.22–4 mm².
The ZS4-OR has an IEC rated current of 32 A and is rated for applications up to 1000 V AC/DC IEC.
The ZS4-OR is designed for mounting on standard TH35-7.5 and TH35-15 DIN rails.
The ZS4-OR has an orange polyamide housing for convenient circuit identification and is supplied in a pack of 50 terminals.
TE Connectivity ENTRELEC SNK terminal blocks provide compact, organised and dependable conductor termination for industrial control panels, machinery and electrical distribution systems worldwide.
