TE Connectivity ZS6-GN 1SNK506061R0000 is a green DIN rail screw clamp feed-through terminal block with 0.2–6 mm² conductor capacity, two positions and IEC ratings of 41 A and 1000 V, supplied in a pack of 50.
£1.47
The TE Connectivity ZS6-GN 1SNK506061R0000 is a robust green screw clamp feed-through terminal block designed for secure conductor connections within industrial control panels, switchgear and automation systems. As part of the TE Connectivity ENTRELEC SNK series, it combines reliable screw clamp termination with a compact DIN rail format for professional electrical installations.
The ZS6-GN provides a single feed-through circuit with two connection positions, making it suitable for straightforward point-to-point wiring and conductor distribution. Its green polyamide housing provides clear visual identification within terminal assemblies, while the screw clamp connection system provides secure mechanical and electrical contact for industrial wiring.
With conductor capacity up to 6 mm², an IEC current rating of 41 A and an IEC voltage rating of 1000 V, the ZS6-GN is suitable for demanding industrial circuits. Its compact 6 mm terminal spacing, IP20 protection and TH35 DIN rail compatibility make it a practical choice for machine builders, panel manufacturers and automation engineers.
Feed-through terminal blocks provide a secure and organised method of connecting conductors across industrial electrical assemblies. They simplify panel wiring by providing accessible connection points on DIN rail, helping engineers create structured circuits that are easier to install, inspect, troubleshoot and maintain.
The ZS6-GN combines secure screw clamp termination with a conductor capacity up to 6 mm² and a narrow 6 mm profile. Its 41 A IEC current rating and 1000 V IEC voltage rating make it suitable for a broad range of power, control and distribution circuits in industrial machinery and automation equipment.
| Manufacturer | TE Connectivity |
|---|---|
| Brand / product family | ENTRELEC |
| Series | SNK / ZS |
| Model | ZS6-GN |
| Manufacturer part number | 1SNK506061R0000 |
| Product type | Screw clamp feed-through terminal block |
| Block function | Feed-through |
| Connection type | Screw clamp |
| Number of levels | 1 |
| Number of circuits | 1 |
| Number of positions | 2 |
| Gauge type | A4-B3 |
| Rated current (IEC) | 41 A |
| Rated current (UL) | 30 A |
| Rated current (CSA) | 30 A |
| Rated voltage (IEC) | 1000 V |
| Rated voltage (CSA) | 600 V |
| Operating voltage (UL / CSA) | 600 V |
| Impulse withstand voltage (IEC) | 8000 V |
| Dielectric withstand voltage | 2200 V |
| Short-time withstand current at 1 s | 720 A |
| Power loss | 1.3 W |
| Flexible conductor range | 0.2–6 mm² / 24–10 AWG |
| Rigid stranded conductor range | 0.2–6 mm² / 24–10 AWG |
| Insulated ferrule capacity | 0.22–4 mm² / 24–12 AWG |
| Non-insulated ferrule capacity | 0.22–4 mm² / 24–12 AWG |
| Twin ferrule capacity | 0.22–2.5 mm² / 24–14 AWG |
| Two flexible conductors per clamp | 0.2–2.5 mm² / 24–14 AWG |
| Two rigid stranded conductors per clamp | 0.2–2.5 mm² / 24–14 AWG |
| Wire stripping length | 10.5 mm |
| Tool size | 4 mm |
| Terminal spacing | 6 mm |
| Housing material | Polyamide |
| Colour | Green |
| Protection rating | IP20 |
| Flammability rating | UL 94V-0 |
| Mounting type | DIN rail |
| DIN rail compatibility | TH35-7.5 / TH35-15 |
| Height | 53 mm |
| Width / spacing | 6 mm |
| Length / depth | 47.3 mm |
| Weight | 10.6 g |
| Operating temperature | -55–110 °C |
| Installation temperature | -5–40 °C |
| Pack quantity | 50 pieces |
| Barcode | 3472595060610 |
The ZS6-GN is a feed-through screw clamp terminal block used to create secure conductor connections in industrial control panels, switchgear, machinery and automation systems.
The ZS6-GN accepts flexible and rigid stranded conductors from 0.2–6 mm², with ferrule capacities varying according to the conductor configuration.
The ZS6-GN has an IEC current rating of 41 A and an IEC voltage rating of 1000 V. Its UL and CSA current rating is 30 A.
The ZS6-GN is designed for DIN rail mounting and is compatible with TH35-7.5 and TH35-15 mounting rails commonly used in industrial electrical cabinets.
The ZS6-GN 1SNK506061R0000 is supplied in a pack quantity of 50 pieces, making it suitable for panel building, machine production and industrial electrical installation projects.
TE Connectivity ENTRELEC SNK feed-through terminal blocks provide panel builders, automation engineers and machine manufacturers with compact, secure and maintainable conductor connections for modern industrial control and power distribution systems.
