Why Choose the IMO PFD2.5LD-220VACBEIGE Push Fit Terminal?
The IMO PFD2.5LD-220VACBEIGE is a compact 2.5 mm² PushFit double-deck feed-through terminal block with integrated 220 V AC LED indication, designed for efficient wiring in industrial control panels, distribution equipment and automation systems. Its double-deck construction provides two connection levels within a narrow terminal footprint, helping maximise wiring density on the DIN rail.
Rated at 24 A, the PFD2.5LD-220VACBEIGE uses IMO's PushFit connection system for quick conductor termination without a conventional screw-clamp connection. It accommodates 0.5–4 mm² solid conductors and 0.5–2.5 mm² flexible conductors, with a recommended stripping length of 10 mm.
The terminal is designed for mounting on 35 × 7.5 mm DIN rail and has a slim width of just 5 mm. Its beige body, integrated 220 V AC LED and compact double-level construction make it particularly useful where visual circuit indication and high terminal density are required within electrical enclosures.
Key Advantages
- PushFit connection technology supports fast and efficient conductor termination.
- Double-deck construction increases connection density while conserving DIN rail space.
- Integrated 220 V AC LED indication provides convenient visual circuit status indication.
- 24 A current rating for industrial control and distribution wiring.
- Nominal 2.5 mm² terminal size.
- Only 5 mm wide, helping optimise panel space.
- Designed for standard 35 × 7.5 mm DIN rail.
- Accepts both solid and flexible conductors across practical industrial wiring ranges.
Key Features
- IMO PushFit terminal range.
- Double-deck feed-through terminal block.
- Integrated 220 V AC LED.
- 24 A rated current.
- 2.5 mm² nominal cross-section.
- 0.5–4 mm² solid conductor capacity.
- 0.5–2.5 mm² flexible conductor capacity.
- AWG 22–12 conductor range.
- 10 mm stripping length.
- 5 mm terminal width.
- Approximately 75.3 mm long and 62.9 mm high.
- Mounting on 35 × 7.5 mm DIN rail.
- Beige terminal body.
Space-Saving PushFit Double-Deck Terminal Technology
Push-fit terminal blocks provide an efficient alternative to traditional screw-clamp connections by simplifying conductor termination and reducing routine wiring work. The IMO PFD2.5LD-220VACBEIGE combines this connection technology with a double-deck architecture, allowing two levels of connections to occupy only 5 mm of DIN rail width.
The integrated 220 V AC LED adds visual indication directly at the terminal block, making the PFD2.5LD-220VACBEIGE useful in circuits where local status indication assists commissioning, inspection or maintenance. Its compatibility with standard 35 mm DIN rail makes it straightforward to integrate into conventional industrial panel layouts.
Typical Applications
- Industrial control panels and electrical cabinets.
- Automation and PLC control systems.
- 220 V AC control and indication circuits.
- Machinery wiring and control circuits.
- Electrical distribution panels.
- High-density DIN rail terminal assemblies.
