Why Choose the IMO PFD2.5LD-24VDCGREY Push Fit Terminal Block?
The IMO PFD2.5LD-24VDCGREY is a compact and reliable 2.5 mm² double-deck push fit feed-through terminal block designed for efficient conductor connections in industrial electrical panels, control cabinets and automation systems. As part of the IMO PF series of DIN rail terminals, it combines space-saving double-deck construction with push fit connection technology and an integrated 24 V DC LED for convenient circuit indication.
The double-deck configuration provides two connection levels within a terminal only 5 mm wide, helping panel builders increase wiring density while conserving valuable DIN rail space. Push fit technology enables quick conductor installation and maintains dependable spring contact without conventional screw clamping, making the terminal well suited to machine building, control panel manufacturing and industrial automation.
With a nominal conductor cross-section of 2.5 mm² and a rated current of 24 A, the PFD2.5LD-24VDCGREY provides dependable connectivity for industrial control and distribution circuits. Its integrated 24 V DC LED provides visual circuit indication, while the grey housing and standard 35 mm DIN rail mounting make it easy to incorporate into organised terminal assemblies.
Key Advantages
- Space-saving double-deck terminal design provides two connection levels.
- Fast push fit connection technology simplifies panel wiring.
- 2.5 mm² nominal cross-section for industrial control and distribution circuits.
- 24 A rated current for dependable electrical connectivity.
- Integrated 24 V DC LED indication assists with circuit status identification.
- Compact 5 mm width helps maximise available DIN rail space.
- Standard 35 mm DIN rail mounting enables straightforward panel installation.
Key Features
- IMO PF series double-deck push fit terminal block.
- 2.5 mm² nominal cross-section.
- 24 A rated current.
- 24 V DC integrated LED.
- Double-deck feed-through configuration for increased wiring density.
- Rigid conductor capacity up to 4 mm².
- Flexible conductor capacity up to 2.5 mm².
- AWG 22–12 conductor compatibility.
- IP20 protection rating.
- 35 mm DIN rail mounting.
- Compact 5 mm width.
- Grey terminal housing for organised panel layouts.
Space-Saving Push Fit Connectivity with LED Indication
Double-deck terminal blocks allow two connection levels to occupy a single DIN rail position, increasing wiring density without unnecessarily expanding the control panel. Combined with push fit connection technology, this configuration provides an efficient solution for high-density industrial wiring where installation speed, reliable conductor retention and compact dimensions are important.
The PFD2.5LD-24VDCGREY also incorporates a 24 V DC LED, providing convenient visual indication within the terminal assembly. This makes it particularly useful in control and automation circuits where quick identification of an energised circuit can assist installation, commissioning, diagnostics and maintenance.
Typical Applications
- Industrial electrical control panels.
- PLC and automation control systems.
- 24 V DC control and signalling circuits.
- Machine building and factory automation.
- High-density control cabinet wiring.
- Power distribution and junction boxes.
- Motor control and process automation panels.
- OEM equipment and panel building.
