Why Choose the IMO SCD2.5CLD48AC Spring Clamp Terminal?
The IMO SCD2.5CLD48AC is a compact 2.5 mm² spring clamp terminal block designed for industrial control and automation circuits requiring 48 V AC operation. Its 2 input, 2 output configuration provides convenient multi-conductor connectivity within a single terminal, helping simplify panel wiring and circuit organisation.
Rated at 20 A, the SCD2.5CLD48AC combines a high-density connection arrangement with spring-clamp conductor termination. The spring mechanism maintains consistent pressure on connected conductors without relying on conventional conductor-clamping screws, providing a practical connection method for machinery, automation systems and electrical control panels.
The SCD2.5CLD48AC is specifically identified for 48 V AC circuits, making it particularly useful where control-voltage connections need to be clearly organised and distributed. Its DIN-rail format and 2 IN / 2 OUT arrangement make it a practical choice for panel builders and machine manufacturers seeking compact, maintenance-friendly terminal connections.
Key Advantages
- Compact 2.5 mm² spring clamp terminal for industrial control wiring.
- Designed for 48 V AC circuits.
- 20 A rated current.
- 2 input, 2 output configuration provides four conductor connection points.
- High-density arrangement helps optimise available DIN-rail space.
- Spring-clamp technology provides consistent conductor retention.
- Eliminates conventional conductor-clamping screws and associated routine tightening.
- Well suited to organised control-voltage distribution within electrical panels.
Key Features
- IMO spring clamp terminal block.
- 2.5 mm² terminal size.
- 48 V AC circuit designation.
- 20 A rated current.
- 2 inputs and 2 outputs.
- Four conductor connection points.
- Spring-clamp conductor termination.
- Compact DIN-rail installation.
- Suitable for industrial automation and control circuits.
- Designed for organised 48 V AC control-voltage wiring.
Compact 2 IN / 2 OUT 48 V AC Connections
Multi-connection terminals provide increased wiring density by accommodating several conductor connections within a compact terminal footprint. The IMO SCD2.5CLD48AC provides two inputs and two outputs, making it useful where 48 V AC control wiring needs to be connected or distributed without installing multiple individual feed-through terminals.
Spring-clamp technology further simplifies installation by maintaining conductor pressure mechanically rather than through a conventional screw connection. Combined with its 2.5 mm² format, 20 A rating and 48 V AC identification, the SCD2.5CLD48AC provides an organised solution for industrial control-voltage wiring.
Typical Applications
- 48 V AC industrial control circuits.
- Industrial automation control panels.
- Machine control systems.
- Control transformer secondary circuits.
- 48 V AC control-voltage distribution.
- Relay and contactor control wiring.
- OEM machinery and electrical equipment.
- DIN-rail terminal assemblies requiring multiple connection points.
