Why Choose the IMO SCD2.5LD110AC Double Deck Spring Clamp Terminal?
The IMO SCD2.5LD110AC is a compact double deck spring clamp terminal block designed for secure and space-efficient electrical connections in industrial control panels, distribution systems and automation equipment. Part of the IMO SCD 2.5 series, it combines two connection levels within a narrow DIN-rail format, helping maximise wiring density where panel space is limited.
The spring clamp connection system provides reliable conductor retention without conventional screw tightening, supporting fast installation and dependable electrical contact in industrial applications. The SCD2.5LD variant incorporates an electronic indication function and is designed for 110 V AC circuits, making it particularly suitable where circuit status indication and compact double-level wiring are required.
With a nominal conductor cross-section of 2.5 mm² and a rated current of 24 A, the SCD2.5LD110AC provides a practical solution for control cabinet and machine wiring. Its slim 5 mm width and double deck construction allow high connection density while retaining straightforward access to conductors.
Key Advantages
- Space-saving double deck spring clamp terminal design.
- Designed for 110 V AC indication circuits.
- 24 A rated current for industrial control and distribution wiring.
- Suitable for conductors up to 2.5 mm².
- Spring clamp technology provides secure, maintenance-friendly conductor connections.
- Compact 5 mm terminal width helps maximise DIN-rail panel capacity.
Key Features
- IMO SCD 2.5 series double deck terminal.
- 110 V AC electronic indication version.
- 24 A nominal current rating.
- 2.5 mm² nominal conductor cross-section.
- Accepts solid conductors from 0.5–2.5 mm².
- Accepts fine-stranded conductors from 0.5–2.5 mm².
- Suitable for AWG 22–12 conductors.
- 10 mm insulation stripping length.
- Compact 5 mm wide double-level construction.
- Designed for mounting on standard industrial DIN rail systems.
Reliable Spring Clamp Connections for Industrial Control Panels
Spring clamp terminal blocks provide consistent conductor pressure without relying on screw connections. This helps reduce installation time and minimises the need for periodic retightening while maintaining secure electrical contact in machinery, control cabinets and industrial automation systems.
The double deck configuration of the IMO SCD 2.5 series places two connection levels within a compact footprint, allowing designers to increase wiring density without significantly increasing DIN-rail space. The SCD2.5LD electronic component version further supports applications requiring local circuit indication.
Typical Applications
- Industrial control panels and electrical cabinets.
- PLC and automation system wiring.
- Machine building and OEM control systems.
- 110 V AC control and indication circuits.
- Distribution panels and junction enclosures.
- High-density DIN-rail wiring installations.
