Why Choose the IMO Spring Clamp Terminal 2.5mm, 220V, 24A, Double Deck SCD2.5LD220AC?
The IMO SCD2.5LD220AC is a compact double-deck spring clamp terminal block designed for efficient conductor termination in industrial control panels, machinery and automation systems. Its double-level construction provides two connection levels within a compact footprint, helping panel builders maximise wiring density where DIN-rail space is limited.
Designed for 2.5 mm² wiring, the SCD2.5LD220AC uses spring clamp connection technology to provide secure conductor retention and consistent contact pressure. This connection method supports fast installation and helps minimise maintenance by eliminating the routine retightening associated with conventional screw-clamp terminals.
With a rated voltage of 220 V AC and a rated current of 24 A, the SCD2.5LD220AC provides a practical terminal solution for industrial power and control wiring where compact double-deck termination is required.
Key Advantages
- Compact double-deck terminal design increases wiring density.
- Reliable spring clamp connection technology for secure conductor termination.
- Designed for 2.5 mm² wiring in industrial electrical installations.
- 220 V AC rated voltage for compatible control and power circuits.
- 24 A rated current for dependable electrical performance.
- Spring clamp technology reduces the need for routine connection retightening.
Key Features
- IMO spring clamp terminal range.
- Double-deck construction for space-efficient wiring.
- 2.5 mm² conductor size.
- 220 V AC rated voltage.
- 24 A rated current.
- Spring clamp conductor connection.
- Compact format for high-density panel wiring.
- Suitable for industrial control and automation applications.
Reliable Double-Deck Connections for Industrial Panels
Double-deck terminal blocks provide two wiring levels in the footprint normally occupied by a single terminal position, allowing panel builders to increase connection density while maintaining an organised wiring layout. This makes them particularly useful in compact control cabinets and machinery where DIN-rail space is valuable.
The spring clamp mechanism of the IMO SCD2.5LD220AC maintains contact pressure on the connected conductor, providing a dependable electrical connection for industrial installations while supporting efficient assembly and maintenance.
Typical Applications
- Industrial control panels.
- Automation and PLC cabinets.
- Machine building and OEM equipment.
- High-density DIN-rail wiring.
- Control and power circuits.
- Electrical distribution and panel assemblies.
