Why Choose the IMO SCD2.5LD48AC Double Deck Spring Clamp Terminal?
The IMO SCD2.5LD48AC is a compact 2.5 mm² double deck spring clamp terminal block designed for industrial control, automation and machinery wiring. Rated at 24 A and configured for 48 V AC indication, it combines spring clamp conductor termination with a space-efficient two-level terminal arrangement.
Spring clamp technology maintains consistent pressure on connected conductors without relying on conventional terminal screws. This provides an efficient method of wiring industrial control cabinets while reducing the requirement for routine terminal retightening and supporting reliable conductor retention.
The double deck configuration provides two connection levels within a compact DIN rail footprint, helping increase wiring density where panel space is limited. Integrated 48 V AC LED indication provides convenient visual circuit status, making the SCD2.5LD48AC particularly suitable for control and signalling circuits requiring straightforward identification during commissioning, operation and maintenance.
Key Advantages
- Compact double deck design increases wiring density within control panels.
- 2.5 mm² nominal terminal size for industrial control wiring.
- 24 A rated current for control and distribution applications.
- 48 V AC LED indication provides convenient visual circuit status.
- Spring clamp technology maintains consistent conductor contact pressure.
- Two-level construction helps conserve valuable DIN rail space.
- No conventional terminal screws requiring routine retightening.
Key Features
- IMO spring clamp terminal block.
- Double deck / two-level configuration.
- 2.5 mm² nominal terminal size.
- 24 A rated current.
- 48 V AC indication voltage.
- Integrated LED visual indication.
- Spring clamp conductor termination.
- DIN rail mounting format.
- Space-saving design for high-density industrial panel wiring.
Space-Saving Connections with 48 V AC Indication
Double deck terminals provide two connection levels within a compact terminal footprint, allowing more conductors to be accommodated along a given length of DIN rail. This arrangement is particularly useful in machinery and automation cabinets where connection density is high and efficient use of enclosure space is important.
The IMO SCD2.5LD48AC combines this space-saving construction with spring clamp termination and 48 V AC LED indication. Visual indication can assist with circuit identification and fault finding, while the spring clamp mechanism provides an efficient conductor connection for industrial control applications.
Typical Applications
- Industrial control panels and cabinets.
- Machine building and OEM equipment.
- PLC and automation systems.
- 48 V AC control and signalling circuits.
- High-density control wiring.
- Motor control and machinery panels.
- DIN rail terminal assemblies requiring visual indication.
