Why Choose the Partex CEF01406G-K 0.14 mm² Insulated Cord End Ferrule?
The Partex CEF01406G-K is a compact and reliable single insulated cord end ferrule designed for the professional termination of small flexible stranded electrical conductors. Featuring a 0.14 mm² conductor size, 6 mm metal barrel length and grey insulated collar, this bootlace ferrule is particularly suitable for fine control wiring, instrumentation circuits and industrial automation applications.
As part of the Partex CEF insulated cord end ferrule range, the CEF01406G-K provides a practical method of consolidating fine copper wire strands into a compact, crimped termination. When correctly installed using a suitable precision ferrule crimping tool, it helps prevent loose conductor strands, supports consistent electrical connections and simplifies insertion into compatible terminal blocks and electrical equipment.
With its 0.14 mm² conductor capacity and compact 6 mm barrel, the CEF01406G-K is designed for smaller conductors commonly encountered in signal wiring, electronic control systems and instrumentation equipment. The grey insulating collar provides a neat transition between the conductor insulation and metal sleeve, while the economical pack of 1000 makes these ferrules ideal for high-volume electrical assembly, panel manufacturing and industrial maintenance.
Key Advantages
- Compact single insulated cord end ferrule for fine flexible stranded conductors.
- 0.14 mm² conductor size suitable for small control and signal wiring.
- 6 mm metal barrel length for compact electrical terminal connections.
- Grey insulated collar for easy conductor insertion and a professional finish.
- Helps prevent stray wire strands and conductor damage during termination.
- Supports secure and consistent crimped electrical connections when correctly installed.
- Suitable for compatible miniature terminal blocks and electrical control equipment.
- Lightweight construction for applications where installation space is limited.
- Bulk pack of 1000 ferrules for efficient electrical manufacturing and assembly.
Key Features
- Partex CEF insulated cord end ferrule series.
- Single conductor ferrule designed for terminating one flexible stranded wire.
- 0.14 mm² nominal conductor cross-sectional area.
- 6 mm conductive metal barrel for compact terminations.
- Grey insulated plastic collar for guided conductor insertion.
- Metal sleeve designed for crimping onto fine stranded copper conductors.
- Helps maintain conductor strand integrity during electrical connection.
- Suitable for precision electrical wiring and industrial instrumentation.
- Designed for use with a crimping tool compatible with 0.14 mm² ferrules.
- Compact format for compatible control and signal terminals.
- 1000 ferrules per pack for bulk installation requirements.
Reliable Crimped Connections for Fine Electrical Conductors
Fine flexible stranded copper conductors are commonly used in industrial control systems, instrumentation circuits and electronic equipment. Their small cross-sectional area makes careful termination particularly important, as individual strands can become displaced or damaged during installation. The Partex CEF01406G-K insulated cord end ferrule provides a practical solution by enclosing the stripped conductor strands within a compact metal sleeve.
During installation, the conductor insulation is stripped to the appropriate length, the exposed strands are inserted fully into the ferrule barrel and the sleeve is compressed using a suitable precision crimping tool. This produces a compact termination that helps keep the fine copper strands together and provides a consistent connection surface for compatible electrical terminals.
The 6 mm barrel length is particularly useful where a short termination sleeve is required, including miniature terminal blocks and compact control equipment. The grey insulated collar helps guide the conductor into the ferrule and provides a neat transition between the wire insulation and the crimped metal barrel.
Supplied in a bulk pack of 1000, the CEF01406G-K is a practical choice for electrical panel manufacturers, instrumentation specialists and automation equipment builders carrying out repetitive fine-wire termination work. The larger pack quantity supports efficient stock management and reduces the need for frequent replenishment during production.
For reliable electrical performance, the ferrule must be matched to the conductor size and crimped using a tool specifically suitable for 0.14 mm² ferrules. The completed termination must also be compatible with the receiving terminal manufacturer's conductor and ferrule specifications.
Typical Applications
- Fine conductor termination in industrial electrical control panels.
- PLC input and output wiring in compatible control terminals.
- Industrial instrumentation and measurement equipment.
- Low-current signal and control circuits.
- Electronic control assemblies and electrical interface equipment.
- Compact terminal blocks and miniature electrical connections.
- Industrial automation and machine control wiring.
- OEM electronic and electrical equipment manufacturing.
- Electrical maintenance, repair and refurbishment.
- High-volume assembly of fine flexible stranded copper conductors.
