Why Choose the Ilme CHCS16 EMC Metal Connector Cover?
The Ilme CHCS16 is a robust EMC metal protective cover for heavy-duty rectangular connectors, designed to protect compatible Ilme connector interfaces while supporting electromagnetic compatibility requirements. Part of the specialised Ilme EMC enclosure series, this cover features four locking pegs and is designed for compatible size 77.27 enclosures equipped with two locking levers.
The CHCS16 uses a specially conductive enclosure treatment to provide increased shielding effectiveness at high frequencies compared with conventional connector enclosures. This makes it particularly suitable for industrial automation, motor control, drives and electronic equipment where electromagnetic interference can affect reliable system operation.
Manufactured from robust die-cast aluminium, the CHCS16 incorporates a retaining eyelet and is designed for the size 77.27 Ilme connector format. The EMC enclosure system supports IP65, IP66 and IP69 protection depending on the complete correctly assembled configuration, while its broad -40 °C to +125 °C operating temperature range makes it suitable for demanding industrial environments.
Key Advantages
- Specialist EMC protective cover for heavy-duty industrial connectors.
- Four locking pegs for compatible enclosures equipped with two locking levers.
- Size 77.27 format for compatible Ilme rectangular connector assemblies.
- Conductive EMC treatment provides enhanced high-frequency shielding performance.
- Supports IP65 / IP66 / IP69 protection within correctly assembled compatible EMC enclosure configurations.
- Robust die-cast aluminium construction for industrial environments.
- Integrated retaining eyelet helps keep the cover with the connector installation.
- Wide -40 °C to +125 °C operating temperature range.
Key Features
- Ilme EMC enclosure series.
- Size 77.27 connector enclosure format.
- Four-peg locking configuration.
- Designed for compatible enclosures with two locking levers.
- Special conductive surface treatment for improved EMC shielding.
- Robust die-cast aluminium body.
- Supplied with retaining eyelet.
- Designed to protect connector interfaces while disconnected.
- -40 °C to +125 °C ambient operating temperature range.
- Suitable for industrial EMC and shielded connector applications.
Reliable EMC Connector Protection for Industrial Equipment
Industrial machinery containing variable speed drives, switching devices, servo systems, control electronics and communication networks can generate or be affected by electromagnetic interference. EMC connector enclosures help maintain shielding continuity around electrical interfaces, reducing unwanted electromagnetic emissions and improving immunity to external interference.
The Ilme CHCS16 combines a conductive EMC enclosure design with robust aluminium construction and secure four-peg locking. When incorporated into a correctly engineered shielded connector installation using compatible Ilme EMC components and suitable EMC cable-entry hardware, it provides dependable protection for disconnected interfaces while supporting the overall electromagnetic compatibility of the equipment.
Typical Applications
- Industrial machinery requiring EMC-compatible connections.
- Variable speed drive and servo motor installations.
- Factory automation and robotic equipment.
- PLC, control and instrumentation systems.
- Industrial communication and data equipment.
- Machine tools and automated manufacturing systems.
- Shielded heavy-duty connector assemblies.
