Why Choose the Ilme CHCW10 W-TYPE Metal Cover?
The Ilme CHCW10 is a robust W-TYPE metal protective cover with four pegs, designed for compatible Ilme heavy-duty connector housings in the size 57.27 format. Developed for aggressive industrial environments, it protects an unused connector interface while providing the corresponding four-peg locking arrangement for housings equipped with two levers.
Manufactured from die-cast aluminium, the CHCW10 belongs to Ilme's W-TYPE enclosure range for demanding environmental conditions. The W-TYPE construction uses enhanced surface treatment and protective coating to improve resistance to corrosion and harsh external conditions, making it particularly suitable for industrial machinery and installations where standard connector enclosures may face greater environmental exposure.
The CHCW10 incorporates an eyelet for convenient retention and has a -40 °C to +125 °C operating temperature range. Its size 57.27 format and four-peg configuration make it a purpose-designed protective accessory for compatible Ilme W-TYPE housings with two locking levers.
Key Advantages
- Heavy-duty W-TYPE protective cover for aggressive industrial environments.
- Four-peg configuration for compatible housings with two locking levers.
- Standard Ilme size 57.27 connector format.
- Durable die-cast aluminium construction.
- Enhanced surface protection for improved resistance in harsh environments.
- Integrated eyelet assists with retaining the cover at the installation.
- Wide -40 °C to +125 °C operating temperature range.
Key Features
- Ilme CHCW10 / CHCW 10 protective cover.
- Part of the Ilme W-TYPE series.
- Designed for aggressive environments.
- 4 pegs for housings with two levers.
- Size 57.27.
- Insert centre distance: 57 × 27 mm.
- Die-cast aluminium body.
- Protective coating for demanding environmental conditions.
- Supplied with eyelet.
- Designed for compatible Ilme heavy-duty connector housings.
W-TYPE Protection for Aggressive Environments
Ilme's W-TYPE enclosure range is designed for industrial applications exposed to particularly aggressive external conditions. Enhanced treatment of the die-cast metal surface and a protective powder coating improve resistance to corrosion and environmental attack, making W-TYPE components suitable for demanding machinery and infrastructure installations.
The CHCW10 provides this rugged construction in a protective-cover format. Its four pegs engage the two locking levers of a compatible housing, allowing the connector interface to be securely covered whenever the mating hood is removed. The integrated eyelet also provides a convenient means of retaining the cover close to the connector during operation or maintenance.
Typical Applications
- Ilme W-TYPE heavy-duty connector assemblies.
- Industrial machinery in aggressive environments.
- Automation and production equipment.
- Material handling and conveyor systems.
- Outdoor and exposed industrial equipment.
- Machine tools and processing machinery.
- OEM equipment requiring enhanced connector protection.
