Why Choose the Ilme CKAX03IA4 Angled Bulkhead Mounting Housing?
The Ilme CKAX03IA4 is a compact and robust metal angled bulkhead mounting housing designed for industrial multipole connector installations. Part of the Ilme CKA series, it uses the compact size 21.21 format and provides a secure equipment-mounted interface for compatible Ilme connector inserts.
The CKAX03IA4 features a durable zinc die-cast housing combined with a stainless steel locking lever and TPE gasket. Its angled construction positions the mating connector away from the mounting surface, helping improve connector accessibility and cable routing in machinery, control panels and other space-restricted industrial installations.
Unlike surface-mount versions with a cable gland entry, the CKAX03IA4 is a bulkhead housing without cable entry and is specifically designed for four-screw fixing. It provides IP44 protection as standard, with IP66, IP67 and IP69 protection available when correctly assembled with the appropriate Ilme CKR 65 sealing system and compatible connector components.
Key Advantages
- Compact size 21.21 angled bulkhead housing for industrial multipole connectors.
- Strong zinc die-cast construction provides dependable mechanical protection.
- Durable stainless steel locking lever for secure connector coupling.
- Four-screw fixing arrangement provides secure attachment to equipment or panel surfaces.
- Angled design improves connector accessibility in restricted installation spaces.
- IP44 protection as standard, with enhanced IP66 / IP67 / IP69 protection available using the appropriate CKR 65 sealing system.
Key Features
- Ilme CKA series metallic connector enclosure.
- Size 21.21 compact enclosure format.
- Angled bulkhead mounting configuration.
- Four-screw panel fixing.
- Designed without cable entry.
- Single stainless steel locking lever.
- Zinc die-cast main housing construction.
- TPE sealing gasket.
- Grey industrial enclosure finish.
- Designed for at least 500 mating cycles.
Reliable Connector Protection with Secure Angled Mounting
Angled bulkhead connector housings provide a fixed electrical interface while positioning the mating connector away from the equipment surface. This arrangement can improve accessibility and cable management where space around machinery, control panels or other equipment is restricted.
The Ilme CKAX03IA4 combines durable metal construction, a stainless steel locking lever and a secure four-screw mounting arrangement. When correctly assembled with compatible Ilme inserts and sealing components, it provides a robust and service-friendly connector interface suitable for repeated connection and disconnection in industrial environments.
Typical Applications
- Industrial machinery and automation equipment.
- Electrical control panels and cabinets.
- Machine-mounted multipole connector interfaces.
- Packaging and production machinery.
- Material handling and conveyor systems.
- OEM equipment requiring compact angled electrical connections.
