Why Choose the ILME CX08CM Male MIXO Modular Insert?
The ILME CX08CM is a compact male MIXO modular insert designed for reliable electrical connections within heavy-duty industrial connector assemblies. Part of the versatile ILME MIXO modular connector series, it provides eight poles with crimp termination while occupying only one module within a compatible MIXO frame.
The CX08CM is rated at 16 A and 400 V under EN 61984 pollution degree 3 conditions, with a rated impulse withstand voltage of 6 kV. Its modular design enables power and control circuits to be combined with other compatible MIXO modules for signal, data and specialist connections within a single heavy-duty connector enclosure.
Featuring 8 male poles, the CX08CM accepts separately ordered ILME 16 A male crimp contacts for conductor sizes from 0.14–4 mm². The insert is suitable for both standard and HNM high-number-of-matings configurations when combined with the appropriate contacts, frames and enclosures, providing excellent flexibility for industrial machinery and automation systems.
Key Advantages
- Compact 8-pole male modular insert for ILME MIXO connector systems.
- 16 A current rating suitable for industrial power and control circuits.
- 400 V rated voltage at pollution degree 3.
- Secure crimp connection allows conductor and contact selection to suit the application.
- Occupies only 1 module within a compatible MIXO frame.
- Suitable for standard and HNM high-number-of-matings connector configurations with appropriate components.
Key Features
- ILME MIXO modular connector series.
- 8-pole male modular insert.
- 16 A rated current.
- 400 V rated voltage.
- 6 kV rated impulse withstand voltage.
- Reliable crimp connection technology.
- Compatible with conductor sizes from 0.14–4 mm² using the appropriate contact.
- Compact 1-module MIXO format.
- Polycarbonate insulating body with UL 94 V-0 flammability rating.
- Suitable for standard and HNM configurations with compatible ILME components.
Reliable Modular Connections for Industrial Equipment
Modular crimp connectors provide machine builders with a flexible method of routing power and control circuits through detachable heavy-duty connector assemblies. The ILME CX08CM provides eight connections within a single MIXO module, helping maximise contact density while retaining the ability to select individual crimp contacts according to conductor size and application requirements.
The MIXO architecture allows the CX08CM to be installed alongside compatible power, signal, data and specialist modules within a common frame and enclosure. When combined with suitable standard or HNM components, the insert can also support applications requiring frequent connector mating and unmating, making it suitable for a broad range of industrial installations.
Typical Applications
- Industrial machinery and machine building.
- Automation and production equipment.
- Power and control circuit connections.
- Motor and drive connection systems.
- Robotics and material handling equipment.
- Configurable heavy-duty industrial connector assemblies.
