Why Choose the ILME CZI15LS Bulkhead Mounting Housing?
The ILME CZI15LS is a robust bulkhead mounting housing with one IL-BRID locking lever and a metal cover, designed for heavy-duty industrial connector assemblies. Manufactured in the size 49.16 format, it provides a secure panel-mounted interface for compatible ILME inserts used in machinery, automation and control equipment.
The integrated metal protective cover helps protect the connector interface when it is disconnected, while the single IL-BRID lever provides secure mechanical coupling with a compatible mating hood or housing. As a bulkhead mounting enclosure, the CZI15LS has no cable entry and is intended for installation through a suitable panel cut-out.
The CZI15LS belongs to the ILME IL-BRID series and provides IP65, IP66 and IP69 protection when correctly assembled in a suitable complete connector configuration. With an operating temperature range from -40 °C to +125 °C, it is suitable for demanding industrial installations requiring reliable connector protection and convenient servicing.
Key Advantages
- Compact size 49.16 bulkhead mounting housing.
- Integrated metal protective cover safeguards the connector interface when disconnected.
- Single IL-BRID locking lever provides secure connector coupling.
- Provides IP65 / IP66 / IP69 protection when correctly assembled.
- Wide operating temperature range from -40 °C to +125 °C.
- Ideal for robust panel-mounted industrial power, control and signal connections.
Key Features
- ILME IL-BRID series enclosure.
- Bulkhead mounting housing configuration.
- Size 49.16 connector format.
- One locking lever.
- Supplied with a metal cover.
- No cable entry, as required for bulkhead mounting.
- Lever manufactured from polyamide with a stainless-steel core.
- Rubber gasket for environmental sealing.
- RAL 7040 grey finish.
Protected Panel-Mounted Industrial Connectivity
Bulkhead mounting housings such as the ILME CZI15LS provide a fixed connector interface on control cabinets, machinery and equipment panels. The size 49.16 housing accommodates compatible ILME inserts while its single IL-BRID lever securely locks the mating cable-side connector in position.
When the mating connector is removed, the supplied metal cover can protect the exposed connector interface from contamination and mechanical contact. Combined with the rubber gasket and suitable mating components, the housing supports high levels of environmental protection for dependable industrial installations.
Typical Applications
- Industrial machinery and machine tools.
- Factory automation equipment.
- Control cabinets and electrical panels.
- Motor and drive connection points.
- Material handling and conveyor systems.
- Industrial production equipment.
- Panel-mounted power, control and signal interfaces.
