Why Choose the EMAS EBM16PD17 16 Pole 16 A Wall Type Socket with Side Entry and 2 Metal Handles?
The EMAS EBM16PD17 is a robust 16-pole, 16 A wall-type industrial socket designed for fixed multipole connections on machinery, automation equipment and electrical control systems. Part of the EMAS EBM Series, it combines a 16-pole female socket connection with a durable metal housing for dependable industrial service.
The EBM16PD17 features a side-entry configuration and two metal locking handles, providing convenient lateral cable routing together with secure mechanical engagement of the compatible mating connector. Its IP65 protection degree, powder-coated metal housing and wide operating temperature range make it suitable for demanding industrial environments.
Designed to TS EN 61984, the EBM16PD17 is rated for 16 A operating current, 690 V insulation voltage and 6 kV impulse withstand voltage. The integrated female socket arrangement provides a serviceable fixed connector interface for machine builders, panel builders and automation engineers who need to connect and disconnect multiple circuits efficiently.
Key Advantages
- Complete 16-pole wall-type socket for industrial multipole connections.
- 16 A operating current for industrial power and control circuits.
- Side-entry configuration supports practical lateral cable routing.
- Two metal locking handles provide secure and durable connector retention.
- IP65 protection degree for demanding industrial applications.
- Robust powder-coated metal housing.
- 690 V insulation voltage and 6 kV impulse withstand voltage.
- Designed in accordance with TS EN 61984.
Key Features
- EMAS EBM Series industrial multipole connector.
- Wall Type Socket configuration.
- 16-pole female socket connection.
- 16 A operating current.
- Side-entry cable arrangement.
- 2 metal handles for secure locking.
- Durable metal body.
- IP65 protection degree.
- Minimum mechanical life of 500 cycles.
- Operating temperature range from -40 to +125 °C.
The EMAS EBM16PD17 provides a fixed female multipole connection point for industrial machinery and electrical equipment. Its 16-pole configuration allows multiple circuits to be grouped within one connector interface, helping simplify machine installation, commissioning and maintenance compared with individually disconnecting multiple conductors.
The combination of a side-entry metal housing and two metal locking handles provides practical cable routing and secure mechanical retention of the mating connector. With a 16 A operating current, IP65 protection and broad temperature capability, the EBM16PD17 is well suited to fixed connector positions in industrial automation, manufacturing machinery and control systems.
Typical Applications
- Industrial machinery and production equipment.
- Factory automation and manufacturing systems.
- Electrical control panels and cabinets.
- Machine building and OEM equipment.
- Fixed wall-mounted multipole connection points.
- Modular production and assembly machinery.
- Industrial power and control connections.
- Equipment requiring secure detachable electrical interfaces.
